Marantz SR5008 - INPUT PCB ASSY

INPUT
7
INPUT PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC4200 963239000650S R2A15218FP-U00R 8CH-VOL WITH 11 INPUT QFP100P J084152180010S 1
IC4206 00D2623727904 NJW1194V-TE1 2CH-ELECT VOL 4IN-1OUT, TONE SSOP32 J084119400010S 1
RESISTOR GROUP
R4205-4211 nsp 470-J,1/16W-1608REEL C20004716M160S 7
R4216-4221 nsp 820K-J,1/16W-1608REEL C20008246M160S 6
R4236 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4244,4245 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R4248 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4249-4252 nsp 470K-J,1/16W-1608REEL C20004746M160S 4
R4257 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4259-4262 nsp 100K-J,1/16W-1608REEL C20001046M160S 4
R4263-4270 nsp 10K-J,1/16W-1608REEL C20001036M160S 8
R4288-4290 nsp 0-J,1/16W-1608REEL C20000006M160S 3
R4292-4294 nsp 0-J,1/16W-1608REEL C20000006M160S 3
R4326 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4332 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4336 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4341 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4344 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4347 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4348,4349 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R4354 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4359 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4360 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4364 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4370-4376 nsp
100-J,1/16W-1608REEL C20001016M160S 7
R4550 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4551,4552 nsp 820K-J,1/16W-1608REEL C20008246M160S 2
R4553 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4554 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
CAPACIITORS GROUP
C4204 nsp COG330PF-J/50V-1608REEL D010331167160S 1
C4209-4211 nsp COG330PF-J/50V-1608REEL D010331167160S 3
C4225-4228 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 4
C4229-4231 963134502430S 47UF-M/63V,6.3*11-5RE RA3-63V470MF3#8P-T2 D040470088210S 3
C4232-4236 963134502370S 47UF-M/16V,5*11-5RE.SMS SY D040470083080S 5
C4237-4239 00D2544574919 47UF-M/50V,6.3*11-5RE.SMS SY (Pb Free) D040470087070S 3
C4240-4244 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 5
C4245,4246 963134501890S 220UF-M/16V,8*11.5-5RE,SMS-SY D040221083090S 2
C4269 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4275 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4280 nsp X7R3300PF-K/50V-1608REEL D011332777160S 1
C4281 nsp 33UF-M/16V,5*11-5RE SMS SY D040330083050S 1
C4282 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4283 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4284 00D9639006476 4.7UF-M/50V,5*11-5RE.SMS SY D0404R7087250S 1
C4287 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4288 00D9639006476 4.7UF-M/50V,5*11-5RE.SMS SY D0404R7087250S 1
C4290 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4293 nsp 33UF-M/16V,5*11-5RE SMS SY D040330083050S 1
C4294 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4295 nsp X7R3300PF-K/50V-1608REEL D011332777160S 1
C4296 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4304 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4550-4553 nsp COG330PF-J/50V-1608REEL D010331167160S 4
C4554 nsp 0-J,1/16W-1608REEL C20000006M160S 1
OTHER PARTS GROUP
CN4006 nsp C125Z2-11 11P BtoB SOCKET(FEMALE) P=1.25MM L109012521120S 1
CN4205 nsp C125Z2-15 15P BtoB SOCKET(FEMALE) P=1.25MM L109012521520S 1
CN4700 nsp C125Z2-13 13P BtoB SOCKET(FEMALE) P=1.25MM L109012521320S 1
CN4701 nsp C125Z2-11 11P BtoB SOCKET(FEMALE) P=1.25MM L109012521120S 1
CN4703 nsp C125Z2-09 9P BtoB SOCKET(FEMALE) P=1.25MM L109012520920S 1
CP4200 nsp C125Z1-25 25P BtoB HEADER(MALE) P=1.25MM L109012512520S 1
CP4201 nsp C125Z1-31 31P BtoB HEADER(MALE) P=1.25MM L109012513120S 1
CP4202 nsp C125Z1-15 15P BtoB HEADER(MALE) P=1.25MM L109012511520S 1
CP4203 nsp C125Z1-07 7P BtoB HEADER(MALE) P=1.25MM L109012510720S 1
CP4204 nsp C125Z1-17 17P BtoB HEADER(MALE) P=1.25MM L109012511720S 1
JACK4201,4202 00D9630132103 RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 2
