Marantz SR5008 - MAIN PCB ASSY

MAIN
1
MAIN PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4000-4004 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 5
D4007 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4008 963203500300D DIODE BRIDGE D10SB60 600V/10A STRAIGHT TYPE K047100600220S 1
D4009-4012 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 4
D4013 00D9630236504 RB721Q-40-DO34-AXIAL LRC K120072140040S 1
D4014,4015 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
D4016 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4017,4018 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
D4019 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4020-4022 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 3
D4023 00D9630236504 RB721Q-40-DO34-AXIAL LRC K120072140040S 1
D4024,4025 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
D4026 00D9630236504 RB721Q-40-DO34-AXIAL LRC K120072140040S 1
D4027-4030 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 4
D4031,4032 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 2
D4033-4036 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 4
D4037 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4038 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4039 00D9630236504 RB721Q-40-DO34-AXIAL LRC K120072140040S 1
IC4000 00D2631100005 KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4001 00D2631099006 KIA7905PI,20W-TO220IS MOLD J126790500070S 1
IC4002 00D2631104001 BA08T 8V TO220FP LOW-DROP POSITIVE VOLTAGE REG J126080000020S 1
IC4003 00D2631100005 KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4004 00D2631251006 KIA7908PI,20W-TO220IS J126790800060S 1
Q4000-4004 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA
J520101411210S 5
Q4005-4009 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 5
ZD4000,4001 963202500360D ZJ33B-0.5W/5MA-52MM SEMTECH K06033R044522S 2
ZD4002 963202500330D ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
RESISTOR GROUP
R4000,4001 963125010110S 470-J,2W-R.REEL C060047166060S 2
R4002 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4003 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4004 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4005 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4006 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4007 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4008 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4009 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4010 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4011 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4012 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4013 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4014 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4015 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4016 nsp 100-J,1/5W-52RE-AX C00001016P520S 1
R4017-4020 nsp 20-J,1/5W-52RE-AX C00002006P520S 4
R4025-4027 963125500070D 1.1K-J,1W-R.REEL C060011265050S 3
R4029 nsp 10K-J,1/4W-R.REEL C060103063050S 1
R4032 nsp JUMPER (0.6/52MM) L045084006040S 1
R4035 nsp 0-J,1/10W-2012REEL C200000060200S 1
R4039,4040 nsp 82K-J,1/16W-1608REEL C20008236M160S 2
R4041 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4042
nsp 33-J,1/16W-1608REEL C20003306M160S 1
R4043 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4046 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4048 nsp 33-J,1/16W-1608REEL C20003306M160S 1
RLY4000 00D9630218409
BC3-12 24V 2A 2ﾈｸｷﾎ 2ﾁ｢ﾁ｡(SMALL SIGNAL)
G680240202030S 1
RLY4001-4004 963682100280D JZC-42F/012-2HST 24.4*12.8*24.8mm G680060103010S 4
CAPACIITORS GROUP
C4000 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4001 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4003 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4004 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4006,4007 nsp MI-0.047UF-J/50V-5RE D020473167050S 2
C4008 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4010,4011 nsp MI-0.047UF-J/50V-5RE D020473167050S 2
C4012 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4014 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4016,4017 nsp MI-0.047UF-J/50V-5RE D020473167050S 2
C4018 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4020 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4021 nsp X7R2200PF-K/50V-1608REEL D011222777160S 1
C4023-4025 nsp MI-0.047UF-J/50V-5RE D020473167050S 3
C4027 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4028 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4030 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4032 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4035 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4038 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4041 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4044 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4047 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4049 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C4050,4051 nsp RED-0.1UF-K/250V-5RE PCMT365 D02010407H080S 2
C4052 963134501800D 10000UF-M/71V,35*50 BULK LAO-71V103MS57P5W1#B
D040103089220S 1
C4053 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4054 963134501800D 10000UF-M/71V,35*50 BULK LAO-71V103MS57P5W1#B D040103089220S 1
C4057 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 1
C4058 963134010700S 2200UF-M/25V,16*25-L.BLK SMS 5.0MC SY D040222084030S 1
C4059 963134011290S 4700UF-M/16V,16*25-L.BLK SMS 5.0MC SY D040472083020S 1
C4060,4061 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4062 00D9630217002 3300UF-M/16V,12.5*25L.BLK SHL 5.0MC SY D040332083010S 1
