Marantz SR5008 - VIDEO PCB ASSY

VIDEO
5
VIDEO PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4210-4212 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 3
D4703 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
IC4700 00D2631286903 PQ120DNA1ZPH 12V 1A SC-63 J126120010010S 1
IC4701 236810090504S ILX3232D 3V3 RS232 INTERFACE TRANSCEIVER SOP16 J046323200020S 1
IC5000 232810005504S BD7628F-E2 2CH VIDEO AMP SOP8P J127762800010S 1
IC5001 963239100770S TC4051BF SINGLE 8CH MUX/DEMUX SOP16 J040405101110S 1
IC5003 963235100630S NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
Q4200,4201 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 2
Q4204 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4205 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4206,4207 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q4208 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4209-4211 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 3
Q4213 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4215,4216 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
ZD4200 963202500290D ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
ZD4700 963202500400S ZJ16B-0.5W/5MA-52MM SEMTECH K06016R044522S 1
RESISTOR GROUP
R4200,4201 nsp 220-J,1/16W-1608REEL C20002216M160S 2
R4202,4203 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R4212,4213 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R4222 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4223,4224 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R4225 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4238,4239 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4240 nsp
470K-J,1/16W-1608REEL C20004746M160S 1
R4241 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4242,4243 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R4258 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4291 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R4295,4296 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R4297,4298 nsp 1K-J,1/5W-52RE-AX C00001026P520S 2
R4299 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4300 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4301 nsp 1K-J,1/5W-52RE-AX C00001026P520S 1
R4302-4305 nsp 470K-J,1/16W-1608REEL C20004746M160S 4
R4708,4709 nsp 1K-J,1/16W-1608REEL C20001026M160S 2
R4710 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4711 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4714 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R5000 nsp 820-D,1/16W-1608REEL C20008211M160S 1
R5001 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R5002 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5003 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R5005 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5006 nsp 680-D,1/16W-1608REEL C20006811M160S 1
R5007 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5008-5010 nsp 10K-J,1/16W-1608REEL C20001036M160S 3
R5011 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5013,5014 nsp 75-J,1/16W-1608REEL C20007506M160S 2
R5015,5016 nsp 150-J,1/16W-1608REEL C20001516M160S 2
R5017,5018 nsp 160-J,1/16W-1608REEL C20001616M160S 2
R5019,5020
nsp 150-J,1/16W-1608REEL C20001516M160S 2
R5021,5022 nsp 160-J,1/16W-1608REEL C20001616M160S 2
R5023,5024 nsp 150-J,1/16W-1608REEL C20001516M160S 2
R5025,5026 nsp 160-J,1/16W-1608REEL C20001616M160S 2
R5033-5035 nsp 75-J,1/16W-1608REEL C20007506M160S 3
R5036 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5037-5039 nsp 75-J,1/16W-1608REEL C20007506M160S 3
CAPACIITORS GROUP
C4200,4201 nsp COG330PF-J/50V-1608REEL D010331167160S 2
C4202,4203 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C4207 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C4220 00D9630244606 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080S 1
C4221,4222 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C4247 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4248-4251 00D9630244606 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080S 4
C4702,4703 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4704-4706 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 3
C4707 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4711,4712 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C4716,4717 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C4718,4719 nsp COG33PF-J/50V-1608REEL D010330167160S 2
C5000 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5001 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C5002,5003 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C5004 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C5006,5007 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 2
C5008-5010 nsp COG68PF-J/50V-1608REEL D010680167160S 3
C5011 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S
1
C5012 nsp COG68PF-J/50V-1608REEL D010680167160S 1
C5013,5014 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C5015,5016 nsp COG68PF-J/50V-1608REEL D010680167160S 2
C5017,5018 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C5019,5020 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C5021 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C5022 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5023-5025 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 3
C5048 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 1
C5051 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 1
OTHER PARTS GROUP
CLAMP300 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
