Marantz SR5008 - FRONT PCB ASSY

FRONT
3
FRONT PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4400 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4401-4405 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 5
D4406,4407 963209003510S CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 2
D4408 963209500020S CDS3C15GTA 1608REEL CERADIODE ESD B72500D0150A060 K067031500010S 1
D4409-4416 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 8
IC4400 963231101200S NJM2887DL3-TE2 TO-252-5 LOW-DROP VOL REGULATOR J126288700010S 1
IC4401,4402 00D2631289900 AZ4580M-TRE1-SOIC8P/DUAL LOW NOISE OP AMP J121458000020S 2
Q4403 00D9630226705 KTC1027Y,1W/TO92L-REEL J5021027Y0020S 1
Q4405-4409 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 5
Q4410 943215500030S RT1P441C 0.2W/SC-59 ISAHAYA J520104411210S 1
ZD4400 nsp JUMPER (0.6/52MM) L045084006040S 1
ZD4401 963202500420S ZJ18B-0.5W/5MA-52MM SEMTECH K06018R044522S 1
ZD4402 963202500430S ZJ24B-0.5W/5MA-52MM SEMTECH K06024R044522S 1
ZD4403,4404 963202500310D ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 2
ZD4407 963202500310D ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 1
RESISTOR GROUP
R4401 00D9639006272 RSD-R1-1WJ-4.7 3*9 P=5MM SMALL R.REEL N113135647920S 1
R4403 nsp JUMPER (0.6/52MM) L045084006040S 1
R4405 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4406 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4409 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R4411 nsp 75K-J,1/16W-1608REEL C20007536M160S 1
R4415 nsp 150K-J,1/16W-1608REEL C20001546M160S 1
R4416 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4418 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4423 nsp
10-J,1/16W-1608REEL C20001006M160S 1
R4425 nsp 10-J,1/16W-1608REEL C20001006M160S 1
R4426 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4429 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R4430-4432 nsp 100-J,1/16W-1608REEL C20001016M160S 3
R4433 nsp 120K-J,1/16W-1608REEL C20001246M160S 1
R4434 nsp 1.2K-J,1/16W-1608REEL C20001226M160S 1
R4435 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4437 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4438 nsp 1.2K-J,1/16W-1608REEL C20001226M160S 1
R4439 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R4441 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4442,4443 nsp 100-J,1/5W-52RE-AX C00001016P520S 2
R4444 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4445 nsp 300-J,1/16W-1608REEL C20003016M160S 1
R4446 nsp 47K-J,1/16W-1608REEL C20004736M160S 1
R4447 nsp 390-J,1/16W-1608REEL C20003916M160S 1
R4448 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4450-4454 nsp 100-J,1/16W-1608REEL C20001016M160S 5
R4455 nsp 18K-J,1/16W-1608REEL C20001836M160S 1
R4456,4457 nsp 4.7K-J,1/5W-52RE-AX C00004726P520S 2
R4458 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R4459 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4460 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4461 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4462 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4465,4466 nsp 100-J,1/5W-52RE-AX C00001016P520S 2
R4467,4468
nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R4469 nsp 100-J,1/5W-52RE-AX C00001016P520S 1
R4470 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4471,4472 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 2
R4473 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4474,4475 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4476 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4477,4478 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4479 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4481 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4483,4484 nsp 4.7K-J,1/5W-52RE-AX C00004726P520S 2
R4485,4486 nsp 0-J,1/16W-1608REEL C20000006M160S 2
R4489,4490 nsp 0-J,1/16W-1608REEL C20000006M160S 2
RMC4400 963262012130S R34ES9A 36KHZ IR REMOCON MODULE P=2.54MM E940349003610S 1
CAPACIITORS GROUP
C4409,4410 nsp RED-0.1UF-K/250V-5RE PCMT365 D02010407H080S 2
C4411 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4412 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4413 nsp JUMPER (0.6/52MM) L045084006040S 1
C4414 00D9630157900 470UF-M/63V,12.5*20 BULK- SHL SY D040471088010S 1
C4416 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4418 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4419 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4421,4422 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4424 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4426 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4427-4429 nsp COG100PF-J/50V-1608REEL D010101167160S 3
C4431,4432 nsp X7R0.1UF-K/50V-1608REEL D011104577160S
2
C4433 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4434 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 1
C4435 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4436 nsp Y5V0.047UF-Z/50V-1608REEL D011473597160S 1
C4437,4438 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C4440,4441 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 2
C4442,4443 nsp COG470PF-J/50V-1608REEL D010471167160S 2
C4444 nsp COG82PF-J/50V-1608REEL D010820167160S 1
C4445 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4446 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C4447 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4448 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
