Marantz SR5008 Service Manual

HDMI
17
REF No. Part No. Part Name Remarks Q'ty New Ver
R2704-2706 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 3
R2707 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2708 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R2709-2716 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 8
R2717 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2718 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2719 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2720 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2721 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2801 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2803 nsp 10-F,1/16W-1005REEL C20001004M100S 1
R2805,2806 nsp 3.3-J,1/16W-1005REEL C2003R306M101S 2
R2812-2816 nsp 33-J,1/16W-1005REEL C20003306M101S 5
R2817 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R2819 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2820 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2822-2825 nsp 10K-J,1/16W-1005REEL C20001036M111S 4
R2826 nsp 1.5K-F,1/16W-1005REEL C20001524M100S 1
R2827 nsp 1.5K-J,1/16W-1005REEL C20001526M101S 1
R2828 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2829,2830 nsp 49.9-F,1/16W-1608REEL C20049R94M161S 2
R2831 nsp 8.2K-F,1/16W-1005REEL C20008224M101S 1
R2832,2833 nsp 49.9-F,1/16W-1608REEL C20049R94M161S 2
R2834 nsp 3.9K-F,1/16W-1005REEL C20003924M100S 1
R2850 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2856 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2859 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2863 nsp 100-J,1/16W-1005REEL C20001016M101S
1
R2864,2865 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R3001,3002 nsp 1K-J,1/16W-1005REEL C20001026M101S 2
R3010,3011 nsp 100-J,1/16W-1005REEL C20001016M101S 2
R3012 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3017 nsp 0-J,1/16W-1608REEL N C20000006M160S 1
R3017 nsp 10K-J,1/16W-1608REEL K C20001036M160S 1
R3018 nsp 0-J,1/16W-1608REEL U C20000006M160S 1
R3018 nsp 10K-J,1/16W-1608REEL K C20001036M160S 1
R3019-3022 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R3023 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3024-3029 nsp 33-J,1/16W-1005REEL C20003306M101S 6
R3030,3031 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R3032-3034 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R3035 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3037 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3038 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3041 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3042,3043 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R3044 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3045 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3048 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3050 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3051 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3058-3061 nsp 33-J,1/16W-1005REEL C20003306M101S 4
R3062 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R3063,3064 nsp 33-J,1/16W-1005REEL C20003306M101S
2
R3065-3067 nsp 1K-J,1/16W-1005REEL C20001026M101S 3
R3068 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3069-3076 nsp 33-J,1/16W-1005REEL C20003306M101S 8
R3077,3078 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R3079 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3081 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3084 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3086 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3088 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3090 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3092 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3094 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3098 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3100 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3103 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R3104-3106 nsp 33-J,1/16W-1005REEL C20003306M101S 3
R3107 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3201 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3202 nsp 2.2M-J,1/16W-1005REEL C20002256M101S 1
R3203 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R3204 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3205 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R3206 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3207 nsp 220K-J,1/16W-1005REEL C20002246M101S 1
R3208 nsp 27K-J,1/16W-1005REEL C20002736M101S 1
R3209 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R3211 nsp 1.2K-J,1/16W-1005REEL
C20001226M101S 1
R3212-3214 nsp 0-J,1/16W-1005REEL C20000006M101S 3
R3215 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3216,3217 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R3218 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R3219 nsp 390-J,1/16W-1005REEL C20003916M101S 1
R3220 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3221 nsp 2.7K-J,1/16W-1005REEL C20002726M101S 1
R3222 nsp 270-J,1/16W-1005REEL C20002716M101S 1
R3223 nsp 470K-J,1/16W-1005REEL C20004746M101S 1
R3224 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3225 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R3226 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3227 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R3228 nsp 100K-J,1/16W-1005REEL C20001046M101S 1
R3230 nsp 18K-J,1/16W-1005REEL C20001836M101S 1
R3231 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3232 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R3234 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R3235 nsp 120K-J,1/16W-1005REEL C20001246M101S 1
R3237 nsp 470-J,1/16W-1005REEL C20004716M101S 1
R3238 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
www.audiodna.sk

Marantz SR5008 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	7
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Power consumption (standby)	0.2 W
Power consumption (typical)	650 W

Weight and Dimensions

Depth	335 mm
Width	440 mm
Height	161 mm
Weight	10100 g
