Marantz SR5008 Service Manual

AMP
11
REF No. Part No. Part Name Remarks Q'ty New Ver
R571,572 nsp 1K-J,1W-R.REEL C060010265050S 2
R573 nsp 270-J,1W-R.RELL C060027165060S 1
R574 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R575 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R576 nsp 270-J,1W-R.RELL C060027165060S 1
R578 nsp 270-J,1W-R.RELL C060027165060S 1
R580 963252100150S DHPTHF1608 471P 115T SMD PTC THERMISTOR F320471001150S 1
R582 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R583 nsp JUMPER (0.6/52MM) L045084006040S 1
R584 nsp 680K-J,1/5W-52RE-AX C00006846P520S 1
R585 nsp 15K-J,1/5W-52RE-AX C00001536P520S 1
R586,587 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R588 963125012630S 22-J,1W-5REEL C060022065050S 1
R589 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R590 nsp 180K-J,1/16W-1608REEL C20001846M160S 1
R591 963125010690S 15K-J,2W-R.REEL C060015366050S 1
R592 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R593 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R595 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R596 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R597,598 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R599 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R600 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R601 nsp JUMPER (0.6/52MM) L045084006040S 1
R602 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R603,604 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R605 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R606 nsp 220K-J,1/5W-52RE-AX C00002246P520S
1
R607 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R608 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R609 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R610 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R611 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R612 963125012630S 22-J,1W-5REEL C060022065050S 1
R613 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R614,615 nsp 1K-J,1W-R.REEL C060010265050S 2
R616 nsp 270-J,1W-R.RELL C060027165060S 1
R617 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R618 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R619 nsp 270-J,1W-R.RELL C060027165060S 1
R621 nsp 270-J,1W-R.RELL C060027165060S 1
R623 963252100150S DHPTHF1608 471P 115T SMD PTC THERMISTOR F320471001150S 1
R625 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R626 nsp JUMPER (0.6/52MM) L045084006040S 1
R627 nsp 680K-J,1/5W-52RE-AX C00006846P520S 1
R628 nsp 15K-J,1/5W-52RE-AX C00001536P520S 1
R629,630 nsp 10K-J,1/5W-52RE-AX C00001036P520S 2
R631 963125012630S 22-J,1W-5REEL C060022065050S 1
R632 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R633 nsp 180K-J,1/16W-1608REEL C20001846M160S 1
R634 963125010690S 15K-J,2W-R.REEL C060015366050S 1
R635 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R636 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R638 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R639 nsp 10K-J,1/16W-1608REEL
C20001036M160S 1
R640,641 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R642 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R643 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R644 nsp JUMPER (0.6/52MM) L045084006040S 1
R645 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R646,647 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R648 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R649 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R650 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R651 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R652 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R653 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R654 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R655 963125012630S 22-J,1W-5REEL C060022065050S 1
R656 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R657,658 nsp 1K-J,1W-R.REEL C060010265050S 2
R659 nsp 270-J,1W-R.RELL C060027165060S 1
R660 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R661 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R662 nsp 270-J,1W-R.RELL C060027165060S 1
R664 nsp 270-J,1W-R.RELL C060027165060S 1
R666 963252100150S DHPTHF1608 471P 115T SMD PTC THERMISTOR F320471001150S 1
R668 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R669 nsp JUMPER (0.6/52MM) L045084006040S 1
R670 nsp 680K-J,1/5W-52RE-AX C00006846P520S 1
R671 nsp 15K-J,1/5W-52RE-AX C00001536P520S 1
R672,673 nsp
10K-J,1/5W-52RE-AX C00001036P520S 2
R674 963125012630S 22-J,1W-5REEL C060022065050S 1
R675 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R676 nsp 180K-J,1/16W-1608REEL C20001846M160S 1
R677 963125010690S 15K-J,2W-R.REEL C060015366050S 1
R678 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R679 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R681 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R682 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R683,684 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R685 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R686 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R687 nsp JUMPER (0.6/52MM) L045084006040S 1
R688 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R689,690 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R691 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R692 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R693 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R694 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R695 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R696 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
www.audiodna.sk

Marantz SR5008 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	7
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Power consumption (standby)	0.2 W
Power consumption (typical)	650 W

Weight and Dimensions

Depth	335 mm
Width	440 mm
Height	161 mm
Weight	10100 g
