Marantz SR5008 - SMPS PCB ASSY

SMPS
8
SMPS PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4140-4148 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 9
D4149 963204500210D S30SC6MT 60V 30A TO-3P(MTO-3PT) SHINDENGEN K120300600010S 1
D4150 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
! IC4140 231010091708S TOP258MG SDIP10 OFF-LINE POWER SUPPLY IC J122258001010S 1
! IC4142 00D2623047008 PC123X2YFZ (DIP4P SHARP) K614123000010S 1
IC4143 212050010508S KIA2431AP,0.7W TO-92 J126243118010S 1
ZD4147-4149 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH U K06039R044522S 3
ZD4150-4157 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 8
ZD4158 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH K06039R044522S 1
ZD4159 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH K06005R644522S 1
ZD4160 00D9600095704 MTZJ6.2B-0.5W/5MA-52MM U K06006R244520S 1
ZD4160 00D2760665903 MTZJ16B-0.5W/5MA-52MM N/K K06016R044520S
RESISTOR GROUP
R4141,4142 nsp 1M-J,1/5W-52RE-AX C00001056P520S 2
R4143 nsp 330K-J,1/5W-52RE-AX C00003346P520S 1
R4145 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4147 nsp 270K-J,1/16W-1608REEL U C20002746M160S 1
R4147 nsp 56K-J,1/16W-1608REEL N/K C20005636M160S
R4148,4149 nsp 2.2M-J,1/5W-52RE-AX U C00002256P520S 2
R4150 nsp 1M-J,1/5W-52RE-AX U C00001056P520S 1
R4151 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R4152 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4153 nsp 6.8-J,1/5W-52RE-AX C0006R806P520S 1
R4154 nsp 10-J,1/16W-1608REEL C20001006M160S 1
R4155 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4156 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4157 nsp 56-J,1/5W-52RE-AX C00005606P520S 1
R4158 nsp 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4159 nsp 5.6K-J,1/5W-52RE-AX C00005626P520S 1
R4160 nsp 22K-F,1/16W-1608REEL C20002234M161S 1
R4161 00D2472041967 6.8K-D,1/16W-1608REEL C20006821M160S 1
R4164 nsp 1M-J,1/5W-52RE-AX C00001056P520S 1
! RLY4140 963682100290D JZC-36FD/005-HLT 23.8*9.5*24.5mm G680060103030S 1
CAPACIITORS GROUP
! C4140,4141 963134011730S DE1B3KX471KB4BL01 AC250V BULK MURATA D00847127H010S 2
! C4142 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 1
! C4143 nsp 0.1UF-K/275V BULK X2 MPX104K3ID2 P=15MM CARLI D02110407H010S 1
C4145-4147 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 3
! C4148,4149 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURATA N/K D008103589010S
C4150 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4151 943134501590S 100UF-M/200V,16*20 BULK NHA SY U D04110108G000S 1
C4151 963134010200S 100UF-M/400V,18*31.5 BULK NHA SY N/K D04110108K000S
C4152 963134010210S 47UF-M/25V,5*11-5RE NXA SY D041470084050S 1
C4153 963132010120S DEHR33A102KB2B D00810207Q010S 1
C4154 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4155 963134010190S 10UF-M/50V,5*11-5RE NXA SY D041100087050S 1
! C4156 963132011930S DE1E3KX222MB4BL01 AC250V BULK MURATA D00822248H010S 1
C4159,4160 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C4161 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4162 963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
C4164,4165
963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 2
C4166 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
OTHER PARTS GROUP
CN4141 nsp 330MM/5P SMH250-05=CKM2509HV-05 WH1007#20 L000331050110S 1
! CP4142 nsp LWBP1143-02P 7.92MM HEADER,VER,2CKT L108011430210S 1
BKT4141 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
BKT4142 nsp AVR3300(E3)(DENON) SPTE 0.8t/SCREW 4010210196000S 1
! F4140 963652010510S T2A/250V-IVBSUCPCcUR S506 U N751502001160S 1
! F4140 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N/K N751501601160S
! F4141 963652010520S T6.3A/250V-IVBSUCPCcUR S506 U N751506301160S 1
! F4141 963652010910S T3.15A/250V-IVBSUCPCcUR S506 N/K N751503151160S
FC4140A nsp PI5.2-REEL G645000050010S 1
FC4140B,4141 nsp PI5.2-REEL G645000050010S 2
FC4141B nsp PI5.2-REEL G645000050010S 1
J4145 nsp JUMPER (0.6/52MM) L045084006040S 1
J4150 nsp JUMPER (0.6/52MM) L045084006040S 1
J4152 nsp JUMPER (0.6/52MM) L045084006040S 1
J4154,4155 nsp JUMPER (0.6/52MM) L045084006040S 2
! JK4140 963641011240S AC0152PPA66 AC INLET 2P_REV1.0 CCC G4300152P0001S 1
JP4140,4141 nsp JUMPER (0.6/52MM) L045084006040S 2
! L4140 963111100420D SQ2014 27mH VERTICAL TYPE LINE FILTER U D320201405510S 1
! L4140 963111100470S SQ2014 50mH VERTICAL TYPE LINE FILTER N/K D320201405000S
! T4140 963102100360S EER2834 SW TRANSFORMER GAP BONDING E060283405530S 1
TR4140 963222500150D KMB2D0N60SA N-CH MOSFET 60V SOT23 J543206005510S 1
TR4142 963213500170D KTC3198G,0.6W/TO92-REEL J5023198G0000S 1
★
nsp AVRE400BKE3(DENON) SPTE 0.3T /CASE 3070210596100S 1
