Marantz SR5008 Service Manual

AMP
12
REF No. Part No. Part Name Remarks Q'ty New Ver
R697 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R698 963125012630S 22-J,1W-5REEL C060022065050S 1
R699 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R700,701 nsp 1K-J,1W-R.REEL C060010265050S 2
R702 nsp 270-J,1W-R.RELL C060027165060S 1
R703-709 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 7
R710-716 nsp JUMPER (0.6/52MM) L045084006040S 7
R717-723 nsp 220-J,1/5W-52RE-AX C00002216P520S 7
R724-730 nsp 56K-J,1/16W-1608REEL C20005636M160S 7
R731,732 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 2
R733,734 nsp 130K-J,1/16W-1608REEL C20001046M160S 2
CAPACIITORS GROUP
C401 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C403 nsp X7R 0.01UF-K/50V-1608REEL D010103777160S 1
C405 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C406 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C407 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C408 00D2544573994 22UF-M/50V,5*11 RA3-50V220ME3#8P-T2 ELNA D040220087330S 1
C409 nsp B470PF-K/500V-5RE D00447127D050S 1
C410 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C411 nsp B470PF-K/500V-5RE D00447127D050S 1
C412 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C413 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C415,416 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C418 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C421 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C422 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C423 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C424 00D2544573994 22UF-M/50V,5*11 RA3-50V220ME3#8P-T2 ELNA
D040220087330S 1
C425 nsp B470PF-K/500V-5RE D00447127D050S 1
C426 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C427 nsp B470PF-K/500V-5RE D00447127D050S 1
C428 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C429 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C431,432 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C434 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C437 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C438 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C439 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C440 00D2544573994 22UF-M/50V,5*11 RA3-50V220ME3#8P-T2 ELNA D040220087330S 1
C441 nsp B470PF-K/500V-5RE D00447127D050S 1
C442 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C443 nsp B470PF-K/500V-5RE D00447127D050S 1
C444 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C445 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C447,448 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C450 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C453 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C454 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C455 00D2544574919 47UF-M/50V,6.3*11-5RE.SMS SY (Pb Free) D040470087070S 1
C456 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 1
C457 nsp B470PF-K/500V-5RE D00447127D050S 1
C458 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C459 nsp B470PF-K/500V-5RE D00447127D050S 1
C460 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C461 nsp
X7R2200PF-K/50V-2012REEL D011222777200S 1
C463,464 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C466 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C469 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C470 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C471 00D2544574919 47UF-M/50V,6.3*11-5RE.SMS SY (Pb Free) D040470087070S 1
C472 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 1
C473 nsp B470PF-K/500V-5RE D00447127D050S 1
C474 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C475 nsp B470PF-K/500V-5RE D00447127D050S 1
C476 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C477 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C479,480 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C482 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C485 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C486 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C487 00D2544574919 47UF-M/50V,6.3*11-5RE.SMS SY (Pb Free) D040470087070S 1
C488 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 1
C489 nsp B470PF-K/500V-5RE D00447127D050S 1
C490 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C491 nsp B470PF-K/500V-5RE D00447127D050S 1
C492 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C493 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C495,496 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C498 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C501 nsp COG220PF-J/50V-1608REEL D010221167160S 1
C502 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C503
00D2544574919 47UF-M/50V,6.3*11-5RE.SMS SY (Pb Free) D040470087070S 1
C504 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 1
C505 nsp B470PF-K/500V-5RE D00447127D050S 1
C506 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C507 nsp B470PF-K/500V-5RE D00447127D050S 1
C508 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C509 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C511,512 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C513,514 00D9630338402 330UF-M/6.3V,6.3*11-5RE SMS SY D040331081050S 2
C515 00D2544538913 22UF-M/16V,5*11-5RE.SMS SY D040220083070S 1
OTHER PARTS GROUP
CN404 963612504740D 170MM/5P 20010HS-05=CKM2002HV-05 YW1007#26 L002171050080S 1
CP401 nsp 20010WS-13A00 DIP13P STRAIGHT L101200101310S 1
CP402 nsp 5267-05A 5P L102526700500S 1
CP403 nsp 20010WS-10A00 DIP10P STRAIGHT L101200101010S 1
CP405 nsp 5267-03A 3P L102526700300S 1
BKT400 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
G400-402 nsp 60MM/1P B1813T0P-2*2 BK1007#20 L000600010050S 3
J592 nsp 0-J,1/16W-1608REEL C20000006M160S 1
JP416 nsp JUMPER (0.6/52MM) L045084006040S 1
www.audiodna.sk

Marantz SR5008 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	7
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Power consumption (standby)	0.2 W
Power consumption (typical)	650 W

Weight and Dimensions

Depth	335 mm
Width	440 mm
Height	161 mm
Weight	10100 g
