Marantz SR5008 - Page 113

Pin Pin Name Symbol I/O Pu/Pd LvCnv STBY STOP
CEC
STBY
Function
88 P72 DIR DOUT I DA3VPu - I I I DIR control pin (PCM9211)
89
P71/CS4#-C/
CS5#-C/CS6#-C/
CS7#-C
DIR CLK O - - L L L DIR control pin (PCM9211)
90
P70/CS3#-B/
ADTRG2#
DIR RST O - - L L L DIR RESET pin (PCM9211)
91 VCC VCC - - - - - - +3.3V
92
PB0/A8/PO24/
TIOCA9
COMP SW2 O - 3->5 L L L
A-VIDEO (COMPONENT) switcher
control pin (NJM2586)
93 VSS VSS - - - - - - GND
94
PA7/A7/PO23/
TIOCA8/TIOCB8/
TCLKH
NC(NR1604)/FIL_
CTRL(SR5008)
O/O - - L L L
FLD Filament voltage on/off pin
(SR5008 only)
95
PA6/A6/PO22/
TIOCA8
VSEL A I - - I I I
Master Volume rotation detection
pin(Rotary encoder)
96
PA5/A5/PO21/
TIOCA7/TIOCB7/
TCLKG
VSEL B I - - I I I
Master Volume rotation detection
pin(Rotary encoder)
97
PA4/A4/PO20/
TIOCA7
NC(NR1604)/VOL
MUTE(SR5008)
O - - L L L VOL MUTE control pin
98
PA3/A3/PO19/
TIOCC6/TIOCD6/
TCLKF
DAC(ETHER)
MUTE
O - - L L L
DAC (ETHER) MUTE control pin
(PCM5100 for DM860)
99
PA2/A2/PO18/
TIOCC6/TCLKE
PRE Z2 MUTE O - - L L L
Z2 PRE OUT MUTE control pin (SR5008
Only)
100
PA1/A1/PO17/
TIOCA6/TIOCB6
CLK MUTE O - - L L L
A.PLD MUTE control pin MUTE
Active="H"
101
PA0/A0/BC0#/PO16/
TIOCA6
PRE MUTE O - - L L L PRE OUT MUTE control pin
102 PE7/IRQ7-A/D15 ADV8003 INT2 I - - I I I HDMI TX INT2 input pin (ADV8003)
103 PE6/IRQ6-A/D14 ADV7850 INT1 I - - I I I HDMI RX INT1 input pin (ADV7850)
104 PE5/IRQ5-A/D13 ADV7850 INT2 I - - L L L HDMI RX INT2 input pin (ADV7850)
105 PE4/D12 ISEL A I/O - - I/L I/L I/L
Input Selector rotation detection
pin(Rotary encoder)
106 PE3/D11 ISEL B I/O - - I/L I/L I/L
Input Selector rotation detection
pin(Rotary encoder)
107 PE2/D10 VOL CLK O - - L L L
FUNCTION / VOLUME control pin
(R2A15218)
108 PE1/D9 VOL DATA O - - L L L
FUNCTION / VOLUME control pin
(R2A15218)
109 PE0/D8 PLD WRITE O - - L L L A.PLD /JTAG switching control pin
110 PD7/D7 JTAG TDO I - - L L L A.PLD rewriting control pin (JTAG)
111 PD6/D6
JTAG TMS/APLD
CS
O/O - - L L L A.PLD rewriting & control pin
112 PD5/D5
JTAG TDI/APLD
DATA/DAC DATA
O/O - - L L L
A.PLD rewriting & control /DAC control
pin
113 PD4/D4
JTAG TCK/APLD
CLK/DAC CLK
O/O - - L L L
A.PLD rewriting & control /DAC control
pin
114 P64/CS4#-B ZVOL LATCH O - - L L L ZONE VOLUME control pin
115 P63/CS3#-A/CS7#-A TRIGGER OUT O - - L L L
DC OUTPUT (12Vdc OUT/Rear Panel)
control pin
116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu - L L L
ETHERNET communication control
pin(DM860)
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/
CS7#-B
DAC MS O - - L L L D/A converter control pin(PCM1690)
118
P60/CS0#/CS4#-A/
CS5#-B
DAC RST O - - L L L D/A converter control pin(PCM1690)
119 PD3/D3 DIRECT LED O - - L L L DIRECT LED Control pin
120 PD2/D2 M-DAX LED O - - L L L M-DAX LED Control pin
121 PD1/D1 FL CLK O - - L L L VFD control pin
122 PD0/D0 FL DATA O - - L L L VFD control pin
123 P97/AN15 DA POWER O - - L L L
DIGITAL AUDIO POWER SUPPLY
(DA3.3V & DA1.2V) control pin.(ON:H)
124 P96/AN14 CEC POWER O - - L L
b
HDMI CEC POWER SUPPLY
(CEC5V & CEC3.3V & CEC1.8V)
control pin.(ON:H)
b
CEC
DBY:MODE1=H,MODE2=H,MODE3=L
153
