IC61 : R5F212AASNFP [HDMI]
Pin
No
Port Name I/O Use Name
PortSetup
Note
Act. Init
1 P33/SSI I/O O HDMI_SCL - H HDMI Devices Control
2 P34/SDA/SCS I/O SDA CPU_SDA - H Communication to Main CPU
3 MODE I I MODE L H L:Boot/H:Normal
4 P43/XCIN I/O O O_HPD_123 H L HPD Output for SRC1,2 and 3
5 P44/XCOUT I/O O N.C. - L Open
6 RESET I I _RST_HDMI_CPU L H Reset Input
7 P47/XOUT (I/)O O XO - - X'tal 20MHz Output
8 VSS/AVSS I I GND - - GND
9 P46/XIN Ｉ(/O) I XI - - X'tal 20MHz Input
10 VCC/AVCC I I +5VH - - +5V
11 P54/TRCIOD I/O O O_5V_CH2 H L +5V Output for HDMI OUTPUT 2 (SR6003 only)
12 P53/TRCIOC I/O O O_5V_CH1 H L +5V Output for HDMI OUTPUT 1
13 P52/TRCIOB I/O O _RST_SW L H HDMI SW Device Reset
14 P51/TRCIOA/TRCTRG I/O O _RST_TX L H HDMI TX Device Reset
15 P50/TRCCLK I/O O _RST_RX L H HDMI RX Device Reset
16 P27/TRDIOD1 I/O O
DEBUG_O7 - L For Debug Use
17 P26/TRDIOC1 I/O O DEBUG_O6 - L For Debug Use
18 P25/TRDIOB1 I/O O DEBUG_O5 - L For Debug Use
19 P24/TRDIOA1 I/O O DEBUG_O4 - L For Debug Use
20 P23/TRDIOD0 I/O O DEBUG_O3 - L For Debug Use
21 P22/TRDIOC0 I/O O DEBUG_O2 - L For Debug Use
22 P21/TRDIOB0 I/O O DEBUG_O1 - L For Debug Use
23 P20/TRDIOA0/TRDCLK I/O O DEBUG_O0 - L For Debug Use
24 P17/TRAIO/INT1 I/O I INT_TX L H HDMI TX Device INT
25 P16/CLK0 I/O O DEBUG_X - L For Debug Use
26 P15/RXD0/(TRAIO)/(INT1) I/O RXD DEBUG_RXD0 - H UART for Debug
27 P14/TXD0 I/O TXD DEBUG_TXD0 - H UART for Debug
28 P86 I/O O No Use - - Pull down to GND
29 P85/TRFO12 I/O O No Use - - Pull down to GND
30 P84/TRFO11 I/O O SW_CLK_SEL L H Audio Clock Select L:HDMI MCLK Enable/H:DIR
31 P83/TRFO10/TRFI I/O O SW_I2S_DSD H L Audio Data Select H:DSD/L:Other
32 P82/TRFO02 I/O O NO USE - L Pull down to GND
33 P81/TRFO01
I/O O SW_VIDEO2 L H Select Video Decorder
34 P80/TRFO00 I/O O SW_VIDEO1 L H Select Video Scaler
35 P60/TRE0 I/O I Rx_MUTEOUT H L HDMI Rx Device MUTEOUT
36 P45/INT0 I/O I INT_RX L H HDMI RX Device INT
37 P66/INT2/TXD1 I/O TXD AUX_TXD - H UART Output for Program
38 P67/INT3/RXD1 I/O RXD AUX_RXD - H UART Input for Program
39 P65/(CLK1)/CLK2 I/O I NO USE - L Pull down to GND
40 P64/RXD2 I/O RXD DEBUG_RxD1 - H UART Input for Debug
41 P63/TXD2 I/O TXD DEBUG_TxD1 - H UART Output for Debug
42 P31/TRBO I/O I SW1 H L Pull down to GND
43 P30/TRAO I/O I SW0 H L Pull down to GND
44 P36/(INT1) I/O I INT_SW L H HDMI SW Device INT
45 P32/(INT2) I/O I _SCDT L H HDMI RX Device SCDT
46 P13/KI3/AN11 I/O O SW_SPDIF - L S/PDIF Select Reserved
47 P12/KI2/AN10 I/O O NO USE - L Pull down to GND
48 P11/KI1/AN9 I/O O NO USE - L Open
49 P10/KI0/AN8 I/O O NO USE - L Open
50 P00/AN7 I/O I I_HPD_CH1 H L HPD Input from HDMI OUTPUT 1
51 P01/AN6 I/O I I_HPD_CH2 H L HPD Input from HDMI OUTPUT 2 (SR6003 only)
52 P02/AN5 I/O I I_5V_CH1 H L +5V from HDMI INPUT 1
53 P03/AN4 I/O I I_5V_CH2 H L +5V from HDMI INPUT 2
54 P04/AN3 I/O I I_5V_CH3 H L +5V from HDMI INPUT 3
55 P62 I/O I NO USE - - Pull down to GND
56 P61 I/O I NO USE - - Pull down to GND
57 P05/AN2/CLK1 I/O I I_5V_CH4 - - Pull down to GND
To Next Page
