FRONT
1
FRONT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D6021 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
D6023,6024 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 2
D6026 943202007690S DIODE,ZENER,1/2W,18V CVDZJ18BT 1
D6027 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT 1
D6029,6030 90M-HI101190R L.E.D,BLUE CVD52CSBBCEAB2 2
D6033,6034 90M-HI101190R L.E.D,BLUE CVD52CSBBCEAB2 2
D6037,6038 263010046507S LED,SUPERRED
CVDBLBUF4V5K1AV
2
D6039-6041 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 3
D6453-6455 963209003510S DIODE,RELIABLEESDPROTECTION
CVDCDS3C05HDMI1
3
D6511 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
D6691 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
D6694 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
D6712 00D2760694903 DIODE,ZENER(CHIP,5.1V) HVDUDZS5.1BSR 1
D6729,6730 00D2760694903 DIODE,ZENER(CHIP,5.1V) HVDUDZS5.1BSR 2
D6752 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
IC601 943232100380S I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTROL CVINJM8080G 1
IC603 963231101200S I.C,REGULATOR(ADJ/TO-252) CVINJM2887DL3 1
IC607 943232100380S I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTROL CVINJM8080G 1
LD601 943263100860M L.E.D,(GREEN/RED3PI) Pd=72mA,If=30mA,Ifp=100mA
CVDWEJ3290W-R2H
1
Q6005 943219006820S T.R CVTKTC1027YT 1
Q6011 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6014-6016 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 3
Q6042 943214500020S T.R,2SC3052 CVT2SC3052 1
Q6081 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6112 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q6152,6153 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q6313,6314 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q6702 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
RESISTOR GROUP
R6001,6002 nsp RES,CHIP(1608/5%/200ohm) CRJ10DJ201T 2
R6003,6004 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6005 nsp RES,CHIP(1608/5%/1ohm) CRJ10DJ1R0T 1
R6006 nsp RES,CHIP(1608/5%/2.2ohm) CRJ10DJ2R2T 1
R6016 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6024 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R6025,6026 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6031 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R6032 nsp RES,CHIP(1608/5%/220Kohm) CRJ10DJ224T 1
R6033,6034 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 2
R6038,6039 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 2
R6041 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6042 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6043 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6044 nsp RES,CHIP(1608/5%/390Kohm) CRJ10DJ394T 1
R6046 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R6049-6051 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6058-6060 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6066-6068 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 3
R6071-6073 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6079-6081 nsp RES,CHIP(1608/5%/180ohm) CRJ10DJ181T 3
R6082 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6084,6085 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R6088,6089 nsp RES,CHIP(1608/5%/330ohm) CRJ10DJ331T 2
R6093-6096 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 4
R6097,6098 nsp RES,CHIP(1608/5%/560ohm) CRJ10DJ561T 2
R6105 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
1
R6106 nsp RES,CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6108 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R6109 nsp RES,CHIP(1608/5%/560ohm) CRJ10DJ561T 1
R6110 nsp RES,CHIP(1608/5%/75Kohm) CRJ10DJ753T 1
R6111 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6112 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R6115,6116 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R6117 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6119 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6121 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6123 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6128 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6147 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6151 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6154 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6155 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6301 nsp RES,CHIP(1608/5%/300ohm) CRJ10DJ301T 1
R6302 nsp RES,CHIP(1608/5%/390ohm) CRJ10DJ391T 1
R6351,6352 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6353,6354 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6421,6422 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6423,6424 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6451 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6452-6454 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
R6503 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6601,6602 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R6603-6605 nsp RES,CHIP(1608/5%/100Kohm)
CRJ10DJ104T 3
R6607 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6613,6614 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6703 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6704 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6711 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6718 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6719 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R6720 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R6721 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6723 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6726 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6734 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
CAPACIITORS GROUP
C6007 nsp CAP,ELECT(63V/470uF) CCEA1JH471E 1
C6008 nsp WIRE,COPPER(D0.6) C3A206 0.02
