Marantz SR7009/U1B - Page 209

FRONT
2
REF No. Part No. Part Name Remarks Q'ty New Ver
C6014 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6021 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6022,6023 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C6025 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6027 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6034 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6046 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6052 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6071-6073 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 3
C6081 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6083 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C6091-6093 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 3
C6094 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6095 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6096-6098 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 3
C6099 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C6113 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6114 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6128 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6151 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6152,6153 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C6353,6354 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H473KCS 2
C6380,6381 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C6423,6424 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H473KCS 2
C6453 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6454 nsp CAP,ELECT(10V/220uF)-S CCEA1AKS221T 1
C6501,6502 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 2
C6511 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T
1
C6512 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6513 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
C6523 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6601 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6603,6604 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C6623,6624 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C6691 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6693 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6702 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6712 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6719 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C6720 nsp CAP,CHIP(1608,50V/82pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H820JAS 1
C6731,6732 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 2
C6733,6734 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H473KCS 2
C6735 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 1
C6753 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6801 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6907 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C6909-6912 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 4
OTHER PARTS GROUP
RC601 262010007707S SENSOR,REMOTE(36.7KHz) CRVHM336R 1
CN602 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1
CN69A nsp WAFER,FFC(40P-1mm,ANGLE) CJP40GB284ZN 1
BK601 nsp BRACKET,PCB CMD1A569-V1 1
BK604 nsp BRACKET,VFD CMD1A793 1
BK605,606 nsp BRACKET,FLT CMD1A209-V1 2
BN605 nsp WIREASS'Y,(5P,100mm,2mmPITCH,UL1007,#24) CWB1C005100CC 1
BN608 nsp WIREASS'Y,(3P,80mm,2mmPITCH,UL1007,#24) CWB1C003080CC 1
BU607 nsp SUPPORT,IR CHG1A533 1
!
F6001 943652000620S FUSE(372Series/100mA/TR5) CBA2D0100A3EYT 1
FL601 17201001300AS VFD,FUTABA,17-BT-040GINK,CIG-TYPE CFL17BT040GINK 1
FL602 172010008005S VFD CFLGP1261AI 1
J6001-6112 nsp WIRE,COPPER(D0.6) C3A206 112
J6114-6121 nsp WIRE,COPPER(D0.6) C3A206 8
J6123-6159 nsp WIRE,COPPER(D0.6) C3A206 37
JK604 943643101590S JACK,USBSTRAIGHT(BLACK1.5A) CJJ9X010Z 1
JK605 90M-YT004500R JACK,PHONES(6.35mm,SILVER) CJJ2E026Z 1
JK606 943643102980S JACK,3P(B/B/B)withS/W,SILVER,VERTICAL CJJ4S051Z 1
JK607 943643102220S JACK,MONO,3.5mm,SILVER CJJ1D004Z 1
JW603 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
L6451,6452 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L6501 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
LUG61 nsp WIREASS'Y CWE8202100RV 1
LUG65 nsp WIREASS'Y(1P) CWE8202080RV 1
S6001-6023 00D9430004402 SW,TACT CST1A012ZT 23
S6024 665010017006S SW,SLIDE(1C2P,12V,0.1A) CSS1B001Z 1
VR601 943663001560S ENCODER(16MM,24PULSES),W/OCLICK CSR2A047Z 1
