Marantz SR7009/U1B - Page 210

FRONTCN T
3
FRONTCNT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC301 943239101080S I.C,DAC(8CH,HTSSOP-48) 24-Bit,192kHzSampling CVIPCM1690DCAR 1
IC302-305 943232100380S I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTROL CVINJM8080G 4
IC311 943239101080S I.C,DAC(8CH,HTSSOP-48) 24-Bit,192kHzSampling CVIPCM1690DCAR 1
IC312-314 943232100380S I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTROL CVINJM8080G 3
RESISTOR GROUP
R3001 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3002 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3003,3004 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R3011-3014 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3015-3018 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 4
R3019-3022 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 4
R3023-3026 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3027,3028 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3029-3032 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3033 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3035 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3036 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3037 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R3038 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3039 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R3040 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3041 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3042 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3043 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3045,3046 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3047 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R3049 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R3053 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3055 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3057 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3059 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3063 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
1
R3065-3068 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3069 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3071 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3073,3074 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3075-3078 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3079,3080 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3081 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3083 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3085,3086 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3101 nsp RES,CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3102 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3103,3104 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R3111-3114 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3115,3116 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3117,3118 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3119-3122 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3123,3124 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3125,3126 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3127,3128 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3129-3132 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3133,3134 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3135,3136 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3137-3140 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3141,3142 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3143,3144 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3145 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3147 nsp RES,CHIP(1608/5%/100ohm)
CRJ10DJ101T 1
R3149-3152 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3153,3154 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3155,3156 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3157-3160 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3161,3162 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3163,3164 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3165,3166 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R9614-9616 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
CAPACIITORS GROUP
C3001 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C3002 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C3003 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C3004 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 1
C3005 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C3006 nsp CAP,ELECT(50V/47uF),ELNA/RA3 CCEA1HRA3470T 1
C3007 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C3012,3013 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) 0+-60ppm/ CCUMUC1H182JAM 2
C3015-3018 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) 0+-60ppm/DoC,CH CCUMUC1H271JAM 4
C3019,3020 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H681JAS 2
C3021,3022 nsp CAP,ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 2
C3023 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) 0+-60ppm/ CCUMUC1H182JAM 1
C3024 nsp CAP,CHIP(2012,50V/1000pF,MURATAGRM21) 0+-60ppm/DoC,CH CCUMUC1H102JAM 1
C3025 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) 0+-60ppm/DoC,CH CCUMUC1H271JAM 1
C3026 nsp CAP,CHIP(2012,50V/150pF,MURATAGRM21) 2012,50V/150pF,MURATAGRM21 CCUMUC1H151JAM 1 *
C3027 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) 0+-60ppm/DoC,CH CCUMUC1H271JAM 1
C3028 nsp CAP,CHIP(2012,50V/150pF,MURATAGRM21) 2012,50V/150pF,MURATAGRM21 CCUMUC1H151JAM 1 *
C3029,3030 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H681JAS 2
C3031 nsp CAP,CHIP(2012,50V/1000pF,MURATAGRM21) 0+-60ppm/DoC,CH CCUMUC1H102JAM 1
C3032,3033 nsp CAP,CHIP(2012,50V/150pF,MURATAGRM21) 2012,50V/150pF,MURATAGRM21 CCUMUC1H151JAM 2 *
C3035,3036 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H681JAS 2
C3037,3038 nsp CAP,CHIP(2012,50V/1800pF,MURATAGRM21) 0+-60ppm/ CCUMUC1H182JAM 2
C3039-3042 nsp CAP,CHIP(2012,50V/270pF,MURATAGRM21) 0+-60ppm/DoC,CH CCUMUC1H271JAM 4
C3043,3044 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H681JAS 2
C3055,3056 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C3057,3058 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 2
C3061-3063
nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 3
C3064-3066 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 3
C3067-3069 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 3
C3101 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
