2CHAMP
9
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
D7808,7809 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7818 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7839 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7908,7909 00D9430182609 DIODE,SWITCHING CVD1SS133MT 2
D7918 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D7939 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
Q7800 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7804 21785000550AS
T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA LOWNOISE,VCBO=VCEO-120V,VEBO-5V,IC-0.1A,PC0.3
CVTHN4A06J 1
Q7814 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7818 00D2710314903 T.R HVTKTA1024YT 1
Q7820,7821 00D2730471907 T.R HVTKTC3206YAT 2
Q7825 963219003340S T.R,BIAS CVTKTC3964 1
Q7831 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7832 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7838 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7839 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q7904 21785000550AS
T.R,PNP,DUAL,HN4A06J,SOT-25,TOSHIBA LOWNOISE,VCBO=VCEO-120V,VEBO-5V,IC-0.1A,PC0.3
CVTHN4A06J 1
Q7914 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7918 00D2710314903 T.R HVTKTA1024YT 1
Q7920,7921 00D2730471907 T.R HVTKTC3206YAT 2
Q7925 963219003340S T.R,BIAS CVTKTC3964 1
Q7931 00D9630235301 T.R,POWER(Pc130W) HVT2SD2560 1
Q7932 00D9630235204 T.R,POWER(Pc130W) HVT2SB1647 1
Q7938 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q7939 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
ZD784 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
ZD794 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 1
R7800 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7801 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7802 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7803 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7804 nsp WIRE,COPPER(D0.6) C3A206 1
R7805 nsp RES,M-OXIDEFILM(1W/1Kohm) CRG1SANJ102RT 1
R7806 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7807 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7808 nsp RES,M-OXIDEFILM(1W/1Kohm) CRG1SANJ102RT 1
R7810 nsp RES,CARBON(1/5W,110ohm,J) CRD20TJ111T 1
R7811 nsp RES,M-OXIDEFILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7812 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7814 nsp RES,METAL(1/2W,27kOHM) METAL(1/2W,27kOHM) CRG12SANJ273T 1
R7816,7817 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R7818,7819 nsp RES,M-OXIDEFILM(1W/270ohm) CRG1SANJ271RT 2
R7820 nsp RES,M-OXIDEFILM(2W/12Kohm) 2W12Kohm CRG2SANJ123RT 1
R7821 nsp RES,M-OXIDEFILM(1W/270ohm) CRG1SANJ271RT 1
R7824 nsp RES,CHIP(1608/5%/2.7Kohm) CRJ10DJ272T 1
R7825 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7826 00MNN05561610 RES,CHIP(1608/5%/560ohm) CRJ10DJ561T 1
R7830 943124500240S RES,M-OXIDEFILM(1W/22ohm) CRG1SANJ220RT 1
R7831-7834 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R7835,7836 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7837 nsp RES,CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7838 252310006506S PTCTHEMISTORS,CHIP(115'C)
1
R7839 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7840 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7841 nsp RES,CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7843 nsp RES,CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R7844,7845 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R7879 943124500240S RES,M-OXIDEFILM(1W/22ohm) CRG1SANJ220RT 1
R7892 943252101000S PTCTHEMISTORS,CHIP(65'C) T=0.8,Vmax=32V,Res(25'C)=470+-50%,OperTemp=-20to90
1 *
! R7896 252310006506S PTCTHEMISTORS,CHIP(115'C)
1
R7900 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7901 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7902 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7903 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7904 nsp WIRE,COPPER(D0.6) C3A206 1
R7905 nsp RES,M-OXIDEFILM(1W/1Kohm) CRG1SANJ102RT 1
R7906 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7907 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7908 nsp RES,M-OXIDEFILM(1W/1Kohm) CRG1SANJ102RT 1
R7910 nsp RES,CARBON(1/5W,110ohm,J) CRD20TJ111T 1
R7911 nsp RES,M-OXIDEFILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7912 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7914 nsp RES,METAL(1/2W,27kOHM) METAL(1/2W,27kOHM) CRG12SANJ273T 1
R7916,7917 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R7918,7919 nsp RES,M-OXIDEFILM(1W/270ohm) CRG1SANJ271RT 2
R7920 nsp RES,M-OXIDEFILM(2W/12Kohm) 2W12Kohm CRG2SANJ123RT 1
R7921 nsp RES,M-OXIDEFILM(1W/270ohm) CRG1SANJ271RT 1
R7924 nsp RES,CHIP(1608/5%/2.7Kohm) CRJ10DJ272T 1
R7925 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7926 00MNN05561610 RES,CHIP(1608/5%/560ohm) CRJ10DJ561T 1
R7930 943124500240S RES,M-OXIDEFILM(1W/22ohm) CRG1SANJ220RT 1
R7931-7934 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R7935,7936 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7937 nsp RES,CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7938 252310006506S PTCTHEMISTORS,CHIP(115'C)
1
R7939 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7940 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7941 nsp RES,CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7943 nsp RES,CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R7944,7945 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R7979 943124500240S RES,M-OXIDEFILM(1W/22ohm) CRG1SANJ220RT 1
C7800 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C7801 00D2544574919 CAP,ELECT(50V/47uF),ELNA/RA3 CCEA1HRA3470T 1
C7802 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7804 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7806 00D2544569937 CAP,ELECT(25V/220uF,ELNA/RA3) CCEA1ERA38P221T 1
To Next Page
