Marantz SR7009/U1B - Page 217

2CHAMP
10
REF No. Part No. Part Name Remarks Q'ty New Ver
C7807 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7812 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7820,7821 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7825 nsp CAP,ELECT(25V/220uF) CCEA1EH221T 1
C7831,7832 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7838 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7891 943134501570S CAP,ELECT(10V/330uF) CCEA1AH331T 1
C7901 00D2544574919 CAP,ELECT(50V/47uF),ELNA/RA3 CCEA1HRA3470T 1
C7902 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7904 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7906 00D2544569937 CAP,ELECT(25V/220uF,ELNA/RA3) CCEA1ERA38P221T 1
C7907 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7912 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7920,7921 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7925 nsp CAP,ELECT(25V/220uF) CCEA1EH221T 1
C7931,7932 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7938 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
OTHER PARTS GROUP
CN462 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY 1
CN705 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/8PIN 2.5MMPITCH/8PIN CJP08GI289ZY 1 *
CN785 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN795 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
BN781
EXPLODED C10
nsp WIREASS'Y(6P,2.0MM,400MM,UL1007#26) WIREASS'Y CWB1B006400LC 1 *
GND79 nsp PLATE,EARTH(TRONICELECTRONICS) CJT1A026 1
J7801-7806 nsp WIRE,COPPER(D0.6) C3A206 6
J7811,7812 nsp WIRE,COPPER(D0.6) C3A206 2
J7821 nsp WIRE,COPPER(D0.6) C3A206 0.02
J7824-7826 nsp WIRE,COPPER(D0.6) C3A206 3
J7831,7832 nsp WIRE,COPPER(D0.6) C3A206 2
J7834-7837 nsp WIRE,COPPER(D0.6) C3A206 4
J7841-7848 nsp WIRE,COPPER(D0.6) C3A206 8
J7851 nsp WIRE,COPPER(D0.6) C3A206 0.03
J7861-7869 nsp WIRE,COPPER(D0.6) C3A206 9
J7871-7876 nsp WIRE,COPPER(D0.6) C3A206 6
J7901-7906 nsp WIRE,COPPER(D0.6) C3A206 6
J7912 nsp WIRE,COPPER(D0.6) C3A206 0.02
J7921 nsp WIRE,COPPER(D0.6) C3A206 0.02
J7923,7924 nsp WIRE,COPPER(D0.6) C3A206 2
J7929 nsp WIRE,COPPER(D0.6) C3A206 0.02
J7931,7932 nsp WIRE,COPPER(D0.6) C3A206 2
J7940-7946 nsp WIRE,COPPER(D0.6) C3A206 7
J7948,7949 nsp WIRE,COPPER(D0.6) C3A206 2
J7951-7954 nsp WIRE,COPPER(D0.6) C3A206 4
J7961-7969 nsp WIRE,COPPER(D0.6) C3A206 9
J7971-7976 nsp WIRE,COPPER(D0.6) C3A206 6
VR784 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR794 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
M15 nsp BRACKET,AMPPCB CMD1A796 1
M16 nsp BRACKET,2CHHEATSINKL CMD1A835
1
M17 nsp HEATSINK,2CH CMY1A398 1
M17 nsp 2CHHEATSINKASS'Y CMY1A398ZA 1
M18 nsp BRACKET,2CHHEATSINKR CMD1A836 1
★ nsp SCREW CTW3+8JR 5
★ nsp SCREW CTB3+8JR 9
★ nsp SCREW CTB3+6FR 1
★ nsp SCREW,SPECIAL CHD3A012R 4
★ nsp SCREW,SPECIAL CHD4A012R 2
★
nsp WASHER,GROUND CNW1A035 1
