Marantz SR7009/U1B - Page 228

CNT
21
CNT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC961 231310009508S I.C,REGULATOR(3.3V) U
CVIPQ033DNA1ZPH
1
IC962 943232100380S
I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTRO
U CVINJM8080G 1
RESISTOR GROUP
R9605,9606 nsp RES,CHIP(1608/5%/39Kohm) U CRJ10DJ393T 2
R9607,9608 00MNN05243610 RES,CHIP(1608/5%/24Kohm) U CRJ10DJ243T 2
R9609,9610 nsp RES,CHIP(1608/5%/100Kohm) U CRJ10DJ104T 2
R9612,9613 nsp RES,CHIP(1608/5%/0ohm) U CRJ10DJ0R0T 2
R9621 nsp RES,CHIP(1608/5%/15Kohm) U CRJ10DJ153T 1
R9622,9623 nsp RES,CHIP(1608/5%/0ohm) U CRJ10DJ0R0T 2
R9624 nsp RES,CHIP(1608/5%/15Kohm) U CRJ10DJ153T 1
R9644-9646 nsp RES,CHIP(1608/5%/0ohm) U CRJ10DJ0R0T 3
CAPACIITORS GROUP
C9601 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R U CCUS1H104KCS 1
C9602-9605 nsp CAP,ELECT(50V/10uF) U CCEA1HH100T 4
C9607,9608 nsp CAP,CHIP(1608,50V/470pF,C0G)_SAMSUNG GeneralCapacitors-C0G U CCUS1H471JAS 2
C9609,9610 nsp CAP,CHIP(1608,50V/33pF,C0G)_SAMSUNG GeneralCapacitors-C0G U CCUS1H330JAS 2
C9611 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R U CCUS1H104KCS 1
C9612 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S U CCUS1A105KCS 1
C9613 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R U CCUS1H104KCS 1
C9614 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S U CCUS1A105KCS 1
C9615-9618 nsp CAP,ELECT(50V/10uF) U CCEA1HH100T 4
C9622 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R U CCUS1H104KCS 1
C9644-9646 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G U CCUS1H101JAS 3
OTHER PARTS GROUP
CN23A nsp PINHEADER(27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN23C nsp PINHEADER(21P,1.25mm,STRAIGHT,B-TO-B) CJP21GI281Z 1
CN27A nsp PINHEADER(15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z 1
CN27B nsp PINHEADER(19P,1.25mm,STRAIGHT,B-TO-B) CJP19GI281Z 1
CN28B nsp PINHEADER(13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z 1
CN64C nsp PINHEADER(13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z 1
CN961 nsp WAFER,FFC(13P-1.25mm,STRAIGHT) U CJP13GA115ZY 1
BN77D nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
JW96 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
JW9601 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
