Marantz SR7009/U1B - Page 229

SMPS
22
SMPS PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D9001-9006 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 6
D9008,9009 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 2
D9010 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D9012 nsp HEATSINKASS'Y(CVDSRL3060P+CMY3A238) AVRX3100W/4100W,SR6009/7009,AV7702 CVDSRL3060PBYA 1
D9013 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
IC901 nsp HEATSINKASS'Y(CVITOP256YN+CMY6A025) AVRX4100,SR7009,AV7702 CVITOP256YNBZA 1
!
IC902 963239010480S I.C,PHOTOCOUPLER CVIPC123Y22FZ0F 1
IC903 212050010508S I.C,SHUNTREGULATOR(TO-92) CVIKIA2431AP 1
Q9001 943229500110S F.E.T,INK0010AC1(N-CH,SC-59,MOSFET,ISAHAYA) CVTINK0010AC1 1
Q9003 943214500020S T.R,2SC3052 CVT2SC3052 1
ZD908 943202500850S TVSDIODE,120V/5W MAXVBR:126V/IR:1uA U/F CVDP6KE120AT 1
ZD911 943202500860S TVSDIODE,150V/5W MAXVBR:158V/IR:1uA CVDP6KE150AT 1
ZD918 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT 1
ZD919 00D9600095607 DIODE,ZENER,1/2W,5.6V CVDZJ5.6BT 1
ZD920 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
ZD921 00D9430196306 DIODE,ZENER,1/2W,7.5V U CVDZJ7.5BT 1
ZD921 943202000940S DIODE,ZENER,1/2W,16V N/K CVDZJ16BT 1 2
ZD921 00D9600095607 DIODE,ZENER,1/2W,5.6V F CVDZJ5.6BT 1
ZD922 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
★ 943209500030S DIODE,LOWFORWARDSCHOTTKYRECTIFIER CVDSRL3060P 1
!
★ 23901007520AS I.C,OFFLINEPOWERSWITCH OFF-LINEPOWERSWITCH,TO-220-7C CVITOP256YN 1
RESISTOR GROUP
R9004 nsp RES,CARBON(1/5W,330Kohm,J) CRD20TJ334T 1
R9006 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R9008,9009 nsp RES,CARBON(1/5W,2.2Mohm,J) U/F CRD20TJ225T 2
R9010 nsp RES,CARBON(1/5W,1Mohm,J) U/F CRD20TJ105T 1
R9014 nsp RES,CHIP(1608/5%/270Kohm) U/F CRJ10DJ274T 1
R9014 nsp RES,CHIP(1608/5%/56Kohm) N/K CRJ10DJ563T 1 2
R9015 nsp RES,CHIP(1608/5%/8.2Kohm) CRJ10DJ822T 1
R9016 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R9017 nsp RES,CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R9018 nsp RES,CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R9019 nsp RES,CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R9020 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R9021 nsp RES,CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R9024 nsp RES,CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R9026 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9027 nsp RES,CARBON(1/5W,4.7Kohm,J) CRD20TJ472T 1
! R9031 943121501000S RES,SURGE,(8.2MOHM,5%,1/2W,PRCTYPE) 8.2MOHM,5%,1/2W,PRCTYPE CRO50TJ825T 1
R9035-9037 nsp RES,CHIP(2012/5%/1Mohm) CRJ18AJ105T 3
!
RY901 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE 1
CAPACIITORS GROUP
!
C9001-9003 963132011940S CAP,CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM 3
C9004
EXPLODED C37
943134503040S CAP,ELECT(200V/220uF),105'C 220uF/200V,16X31.5L,NHA U/F
CCET200NHA221ES
1
C9004
EXPLODED C37
963134010200S CAP,ELECT(400V/100UF,18X40,NHA) N/K
CCET400NHA101ES
1 2
C9006 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H473KCS 1
C9007 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C9008 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C9009 00D9430175108 CAP,ELECT(50V/10uF),105'C CCEA1HNXA100TS 1
C9010 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C9012 963132010120S CAP,CERAMIC(DC1KV/1000pF) CCKDDEH102KCM 1
C9016 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C9017 00MOA47602520 CAP,ELECT(25V/47uF),105'C CCEA1ENXA470TS 1
C9018 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C9019 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 1
C9020-9022
EXPLODED C32-
963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES 3
C9024 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
! C9028 963132011930S CAP,CERAMIC(X1/Y1,2200P,AC250V) CCKDKX222MEM 1
C9029 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
OTHER PARTS GROUP
CN901 nsp WAFER,2P,3.96mm CJP02KA060ZY 1
CN902 nsp WAFER,2P,7.92mm CJP02GA89ZY 1
!
CX901,902 943139500020S CAP,POLYPROPYLENEFILM(0.1uF/275VAC) CCQF2E104KZE-T 2
! CY901,902 963134011730S CAP,CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM 2
BK901,902 nsp BRACKET,PCBM3 CMD1A834 2
BK903 nsp BRACKET,PCB CMD1A629 1
BN903
EXPLODED C35
nsp WIREASS'YLOCKING(5P,2.5MM,400MM,UL1569#22,105) 5P,2.5MM,400MM,UL1569#22,105 CWB7D0054003D 1
F9001,9002 nsp HOLDER,FUSE KJCFC5S 2
J9002-9011 nsp WIRE,COPPER(D0.6) C3A206 10
JW902 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
!
LF901
EXPLODED C38
943111101290S LINEFILTER(1.2A,29mH) LINEFILTER,1.2A,29mH,120V U/F CLZ9Z176Z 1 5
!
LF901
EXPLODED C38
943111101300S LINEFILTER(0.7A,65mH) LINEFILTER,0.7A,65mH,220-230V N/K CLZ9Z177Z 1 2, 5
!
T9001
EXPLODED C36
943102100350S TRANS,SWITCHING TT3-ASST00204 CLT9Z093ZE 1
nsp RUBBER,TRANS 89x10x3t CHG1A587 1
M24 nsp HEATSINK,TR CMY6A025 1 *
M25 nsp SHEILD,TRANSCOVER CMC1A445 1
M26 nsp TRHEATSINK CMY3A238 1
nsp TAPE,BOTHSIDE C4FA101 0.02
nsp SCREW CTW3+10JR 1
nsp SCREW CTB3+8JR 1
