CX870CONNEC TOR
37
CX870CONNECTOR PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC911 943239101090S I.C,Highsideswitch(TSSOP-B8) 1CH,short-circuitcurrent1.5A,ActiveHigh CVIBD82065FVJ-E2 1
IC921 nsp MODULE,BLUETOOTH,CLASS2,IBT-06-02 3.3Vto4.2V,I/OSupplyVoltage:1.8Vto3.3V CNVIBT-06-02 1
IC922 00MHC012405KY I.C,INVERTER(SON5-P-0.50) 3.6VTOLERANTINPUT CVITC7SGU04FE 1
IC923 943231101890S I.C,LDOREGULATOR(HTSOP-J8) VARIABLE300mA,FIXEDOUTPUT
CVIBD00HA3WEFJ-E
1
RESISTOR GROUP
R9102,9103 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R9106 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9107-9112 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 6
R9113 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9114 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T 1
R9116 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9119 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9122,9123 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R9124,9125 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 2
R9127 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9141-9152 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 12
R9161,9162 nsp RES,CHIP(1005/5%/2.2Kohm) CRJ06IJ222T 2
R9191 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R9202 nsp RES,CHIP(1005/5%/680Kohm) CHIP(1005/5%/680Kohm) CRJ06IJ684T 1 *
R9203,9204 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R9206 nsp RES,CHIP(1005/5%/10Mohm) CHIP(1005/5%/10Mohm) CRJ06IJ106T 1 *
R9207 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9211 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9213 nsp RES,CHIP(1608/5%/11Kohm) CRJ10DJ113T 1
R9214 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
RN911 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 1
RN913 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 1
RN915 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 1
CAPACIITORS GROUP
C9105,9106 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C9107-9110 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 4
C9113 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C9114-9117 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 4
C9201,9202 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 2
C9203-9205 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 3
C9206 nsp CAP,CHIP(1608,50V/27pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H270JAS 1
C9207 nsp CAP,CHIP(1608,50V/22pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H220JAS 1
C9211 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C9213 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
OTHER PARTS GROUP
CN911 nsp WAFER,120PINH=4.5mmp=0.5mm DC0.4A/50V CJP120GA313ZR 1
CN914 nsp LOCK-WAFER/ANGLE/2MMPITCH/5PIN CJP05GJ288ZY 1
CN915 nsp WAFER,SMTRIGHTANGLE 4P,2.0MMPITCH,ANGLETYPE CJP04GB220ZY 1
CN916 nsp LOCK-WAFER/ANGLE/2MMPITCH/11PIN CJP11GJ288ZY 1 *
CN917 nsp WAFER,FFC,SMD(07P-1mm,STRAIGHT) CJP07GA193ZY 1
BK911,912 nsp BRACKET,NETWORKB CMD1A902 2
BN501,502 nsp WAFER,64pin(2x32x1.27mm)FEMALESMDTYPE 1.27FEMALEHEADER2*32PSMD CJP64GA314ZP 2
BN921 nsp WIREASS'YLocking(YH)(11P,2MM,600MM,#26) WIREASS'Y
CWB7B011600HC00
1 *
JW913 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
L9101,9102 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L9201,9202 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
X9201 943141101250S X-TAL,SMD(32.768KHz/12.5pF,FC-135,3.2x2.5) SMD3.2x2.5,32.768KHz,12.5pF COX00032I125SP 1
