EXPLODED
38
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
C1 nsp FRONT PCB DOOR SW U/F/N COP12433-3 1
C1 nsp FRONT PCB DOOR SW K COP12433-3 1 2
C2 nsp FRONT PCB HEADPHONE COP12433-2 1
C5 nsp FRONT PCB FRONT COP12433-1 1
C7 nsp FRONT PCB GUIDE FFC (with FRONT PCB) COP12433-5 1
C48 nsp FRONT PCB GUIDE FCC (with DIGITAL PCB) COP12433-8 1
- 943639101760M INPUT PCB ASSY U/F COP12633F 1 *
- 943639101770M INPUT PCB ASSY N COP12633G 1 *
- 943639101780M INPUT PCB ASSY K COP12633J 1 * 2
C3 nsp INPUT PCB FRONT HDMI COP12633-2 1
C39 nsp INPUT PCB INPUT COP12633 1
C43 nsp INPUT PCB HDAM CONNECT-5 COP12633-6 1
C44 nsp INPUT PCB HDAM CONNECT-4 COP12633-7 1
C45 nsp INPUT PCB HDAM CONNECT-3 COP12633-5 1
C9 nsp 2CH AMP COP12626-1 1 *
C12 nsp SIDE CNT PCB GUIDE L COP12631-3 1 *
C13 nsp SIDE CNT PCB GUIDE R COP12631-4 1 *
C16 nsp SIDE CNT PCB GUIDE (with 7ch AMP PCB) COP12631-2 1 *
C19 nsp SIDE CNT PCB SIDE CONNECT COP12631 1 *
C17 nsp SPK_REG (MAIN) PCB SPK_FUSE COP12628-2 1 *
C20 nsp SPK_REG (MAIN) PCB SPK_REG COP12628-1 1 *
C47 nsp SPK_REG (MAIN) PCB SPK_FH COP12628-3 1 *
C18 nsp FRONT CONNECT COP12686 1 *
C31 nsp SMPS COP12642 1 *
C42 nsp HDAM COP12635 1 *
C14 nsp 7CH AMP COP12625 1
C46 nsp VIDEO COP12524 1
C49 9U6391018400M DIGITAL PCB ASSY U CX870 Model COP12719F 1 *
C49 9U6391018100M DIGITAL PCB ASSY N CX870 Model COP12719G 1 *
C49 9U6391017600M DIGITAL PCB ASSY F CX870 Model COP12719H 1 *
C49 9U6391017900M DIGITAL PCB ASSY K CX870 Model COP12719J 1 * 2
C49 9U6391016100M DIGITAL PCB ASSY (U) U CY920 Model COP12637F 1 * 3
C49 9U6391016200M DIGITAL PCB ASSY (N) N CY920 Model COP12637G 1 * 3
C51 943189101130M CX870 MIDDLE / BT BASE ASSY(U/N/F/K) CX870 Model COP12666F 1 *
C5 943606502610S CARDCABLE,(1mm/23P/350mm/B/SHIELD) ALLALUMINUMSHIELD
1 *
C6 nsp WIREASS'Y(5P,2.0MM,600MM,UL2725#24/#28,1P+2C)USB WIREASS'Y,SPECIALSHIELD CWB8A005600HC 1
! C30 943101102580D TRANS,POWER(EI96X75) EI96X75,FORNA U CLT5V069ZU 1 *
! C30 943101102550D TRANS,POWER(EI96X75) EI96X75,FOREU/AP N CLT5V069ZE 1 *
! C30 943101102570D TRANS,POWER(EI96X75) EI96X75,FORJAPAN F CLT5V069ZJ 1 *
! C30 943101102560D TRANS,POWER(EI96X75) K CLT5V069ZH 1 * 2
C50 943183100370D TUNER,MODULE(HDRADIO) HDRADIO,WNC(WistronNeWebCorp.) U CNVUMH-AVR 1
C52 943189101250M IC,CX870MODULE(SR7009/U) CX870MODULE U CX870 Model CVIANAM2064AV 1 *
C52 943189101220M IC,CX870MODULE(SR7009/N) CX870MODULE N CX870 Model CVIANAM2065AV 1 *
C52 943189101170M IC,CX870MODULE(SR7009/F) CX870MODULE F CX870 Model CVIANAM2066AV 1 *
C52 943189101200M IC,CX870MODULE(SR7009/K) CX870MODULE K CX870 Model CVIANAM2067AV 1 * 2
C52 943189100890M CY920 MODULE ASSY (N) CY920 Model CVIANAM2026AV 1 * 3
C53-1 943116100580S WIFI ANT WIRE ASSY 300MM - 1 * 4
C53-2 943116100570S WIFI ANT WIRE ASSY 450MM - 1 * 4
C54 - 2PWIREASS'Y(100MM) CWZPM5003TW91A 1
C55 nsp TERMINAL,GROUND CMA1A006 1
C8 943606502130M CARDCABLE(1mm/40P/270mm/B/sheild) 1mm/40P/270mm/B/sheild
1
M1 421410006004M BADGE,MARANTZ CGB1A206 1
M10 nsp EARTH,AUX CMC1A434 1
M11 nsp EARTH,FRONT CMC1A437 1
M12 nsp EARTH,EMC CMC1A456 1
M13 nsp BRACKET,BODY CMD2A668 1
M14 00M05CW257010 CABINET,TOP BK BK CKC1A170K117 1
M14 943403100670M CABINET,TOP SG SG CKC1A170D11 1
M2 943402104800M U1B CKM1A249MC23 1 *
M2 943402104780M PANEL,ALFRONT SR7009/N1B N1B/K CKM1A249LC23 1 * 2
M2 943402104770M PANEL,ALFRONT SR7009/N1SG N1SG CKM1A249KC62 1 *
M2 943402104760M PANEL,ALFRONT SR7009/FN FN CKM1A249JC62 1 *
M20 nsp CHASSIS,BOTTOM CUA2A338 1
M21 nsp BRACKET,FAN CMD1A837 1
M22 nsp BRACKET,SCREWCOVER CMD1A813 1
M23 nsp BRACKET,SMPS CMD1A838 1
M27 nsp PCBBRACKET(HDMI) CMD1A791 1
M28 nsp PANEL,REAR SR7009/U U CKF1A484Z 1 *
M28 nsp PANEL,REAR SR7009/N N CKF2A484Z 1 *
M28 nsp PANEL,REAR SR7009/F F CKF2A484Y 1 *
M28 nsp PANEL,REAR K CKF2A484X 1 * 2
M29 nsp WASHER,GROUND CNW1A035 4
M29 nsp WASHER,GROUND CNW1A035 8
M3 412410005014M VOLUMEKNOBASS'Y BK
BK CGK1A133YA 2
M3 943412002020M VOLUMEKNOBASS'Y SG SG CGK1A133XA 2
M4 943424100350M RING BK BK CGK1A163C23 1
M4 943424100360M RING SG SG CGK1A163C62 1
M5 415410001011M DOOR,ALFRONTAV8003 BK BK CKM2A195C23 1
M5 415410023134M DOOR,ALFRONT SG SG CKM2A195C62 1
M6 00M10BW112010 BASE,SHAFT CDF1A018 2
M7 00M10BW104010 BRACKET,BASE CMD1A542 1
M8 00M10BW305010 MAGNET,BASE CJC1A008 1
M9 nsp EARTH,USB CMC1A435 1
P1 943424101060M ORNAMENT,INNERDOOR BK BK CGR1A457V 1 *
P1 943424101070M ORNAMENT,INNERDOOR SG SG CGR1A457RMUD10 1 *
P10 424510002017M ORNAMENT,VOLUME BK BK CGR1A449B37 2
P10 943424002030M ORNAMENT,VOLUME SG SG CGR1A449RMD10 2
P11 00M446T056010 CUSHION,DOOR CHG1A296Y 2
P12 943402103950M PANEL,SIDE L BK BK CGW1A453RNVB37 1
P12 943402103960M PANEL,SIDE L SG SG
1
P13 443510045107M PANEL,SUB BK BK CGW1A526B37 1
P13 443510045138M PANEL,SUB SG SG CGW1A526RMD10 1
P14 943402105200M PANEL,SIDE R BK BK CGW2A454RNB37 1 *
P14 943402105210M PANEL,SIDE R SG SG CGW2A454ROD10 1 *
P15 00M10BW355010 INDICATOR,POWER CGL1A231 1
P16 411510015017M KNOB,TACTPOWERAV8003/U BK BK CBT1A1072 1
P16 411510021036M KNOB,POWER SG SG CBT1A1072RMD10 1
P17 943474001390S GEAR,DEMPERAV8003 CDG1A027Z 1
P18 411510120001M 4KEYBUTTONASS'Y BK BK CBT1A1170ZA 1
