Marantz SR7009/U1B - Page 246

EXPLODED
39
REF No. Part No. Part Name Remarks Q'ty New Ver
P18 411510120032M 4KEYBUTTONASS'Y SG SG CBT1A1170YA 1
P19 943412101120M BUTTON,11KEY BK BK CBT1A1169B37 1
P19 943411101970M BUTTON,11KEY SG SG CBT1A1169RMD10 1
P2 454510002018M HOLDER,DOORAV8003 BK BK CKG1A053B37 1
P2 417510015039M HOLDER,DOOR SG SG CKG1A053RMD10 1
P20 943411101980M BUTTON,CURSOR BK BK CBT1A1171Z 1
P20 943411101990M BUTTON,CURSOR SG SG
CBT1A1171RMYD10
1
P21 nsp CUSHION,EVA 70x35x3t CHG1A590 1
P23 nsp SHEET,SCREW CGX1A439 1
P22 nsp CUSHION,EVA 70x35x3t CHG2A590 1 *
P24 nsp CUSHION,SUPPORT CHG1A305 4
P25 nsp RUBBER CHG1A113 5
P26 nsp FOOT,FRONT CKL2A042H46 4
P27 nsp EOLitemCUSHION,FOOT CHG1A360 4
P28 nsp SUPPORT,PCB CMH1A334 1
P29 nsp SUPPORT,PCB CMH1A328 1
P3 943422100480M SHEET,JACK BK BK CGX1A475Z 1
P3 943422100490M SHEET,JACK SG SG CGX1A475Y 1
P30 nsp SPACER,PCB CRE1A107 2
P31 nsp SUPPORT,RUBBER CHG1A535 1
P32 nsp SUPPORT,PCB CRE1A102 1
P33 nsp SPACER,PCB KCA-20(20mm) CRE1A116 2
P34 nsp ORNAMENT,REARPANELA SR7009 CGX1A511Z 1 *
P35 nsp ORNAMENT,REARPANELB SR7009 CGX1A512Z 1 *
P36 nsp LABEL,LICENSE SR7009U U CQB1A1315Z 1 *
P36 nsp LABEL,LICENSE SR7009N N/F/K CQB1A1314Z 1 * 2
P37 nsp LABEL,POP SR7009/U U CQB1A1288Z 1 *
P37 nsp LABEL,POP SR7009/N N CQB1A1289Z 1 *
P37 nsp LABEL,POP K CQB1A1291Z 1 * 2
P4 943422101050M WINDOW,VFD SR7009BK BK CGU1A466V 1
*
P4 943422101060M WINDOW,VFD SR7009SG SG CGU1A466U 1 *
P5 481510019100M LENS,IR BK BK CGU1A460 1
P5 481510019131M LENS,IR SG SG CGU1A460Y 1
P6 481510018107M LENS CGL1A290 1
P7 nsp SHEET,DIFFUSION CGX1A455Z 1
P8 416510046009M WINDOW CGU1A455 1
P9 416510047101M SHEET,VFD CGX1A449Y 1
S1 nsp SCREW BK CTB3+8JFZR 9
S1 nsp SCREW SG CTB3+8JFN 9
S10 nsp SCREW CTW3+16JR 1
S11 nsp SCREW,TRANS CHDR1A023R 4
S12 nsp SCREW CTB3+6JR 1
S13 nsp SCREW,SPECIAL CHD1A109JFN 2
S14 nsp SCREW CTB26+8JFZR 3
S15 nsp SCREW,DOT CTBD3+8JFB 36
S15 nsp SCREW,DOT CTBD3+8JFB 2
S16 nsp SCREW,DOT CTBD3+6FFB 14
S17 nsp SCREW CTB3+8JFB 2
S18 nsp SCREW BK CTW3+8JFZR 6
S2 nsp SCREW CTB3+8JR 10
S2 nsp SCREW CTB3+8JR 26
S3 nsp SCREW CTB3+10JR 37
S4 nsp SCREW CTB3+6FR 2
S4 nsp SCREW CTB3+6FR 6
S5 nsp SCREW CTWS3+10JR 1
S6
nsp SCREW CTW3+8JR 2
S6 nsp SCREW CTW3+8JR 8
S9 nsp SCREW CTW3+12JR 2
★
nsp SCREW SG CTW3+8JFC 6
★ nsp LABEL,POWER K CQB1A1006U 1 2
★
nsp PLATE,EARTHAV8003 CMC1A340 1
★
943671101000D ENCODER(16MM,12PULSES) Operatingtemperaturerange:-10'Cto+70'C CSR2A060Z 1
★ nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
★
nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
!
F9001 963652010510S FUSE(S506Series,250V,2A) U/F CBA2C2000TLEC 1 2
! F9001 963652010500S FUSE(S506Series,250V,1.6A) N/K CBA2C1600TLEC 1 2
! F9002 90M-FS001220R FUSE(218Series,250V/8A) U/F KBA2C8000TLEY 1 2
! F9002 90M-FS001490R FUSE(218Series,250V/4A) N/K KBA2C4000TLEY 1 2
!
★
963652010510S
FUSE(S506Series,250V,2A) CBA2C2000TLEC 1
! ★ 963652010510S FUSE(S506Series,250V,2A) CBA2C2000TLEC 1
! ★ 963652010510S FUSE(S506Series,250V,2A) CBA2C2000TLEC 1
!
★ 963652010510S FUSE(S506Series,250V,2A) CBA2C2000TLEC 1
! ★ 963652010510S FUSE(S506Series,250V,2A) CBA2C2000TLEC 1
! ★ 943652500530D FUSE(215Series,250V/12A) 250V/12A CBA2C1202TLHEY 1
! ★ 943652500530D FUSE(215Series,250V/12A) 250V/12A CBA2C1202TLHEY 1
!
★
00MYJ04002640 RECEPTACLE,AC(15A/250V,R-301,B21) CJJ8A006ZW 1
★ nsp SCREW,SPECIAL CHD1A036FZR 2
★ nsp TAPE,CLOTH CHS1A201 0.25 *
★ nsp LOCKER N/K CRE1A037 22 2
★ 943606501260S CARDCABLE(1.25mm/13P/80mm/B) U
CWC4F2A13B080B1
1
★ nsp WIREASS'Y(4P,2.0MM,80MM,UL1007#24) WIREASS'Y CWB1C004080LL 1 *
★ nsp 2PWIREASS'Y(100MM) CWZPM5003TW91 1
★
nsp CLAMPER,WIRE CHE36-3 2
