Marantz SR7009/U1B - Page 30

Conrmation item FL display Settings Contents of conrmation
A15
Front Wide (signal) Path
A 1 5 F W
* * * . * d B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Vol : 60.0 ( -20dB )
Amp assign : 11.1ch
Height Speakers = 4Height Speakers
Height Layout = Top Front & Top Middle
Speaker Cong >> S.Bakck = None
MAIN ZONE ON
ZONE2 OFF
·Analog input
⇒
Speaker output ( Front Wide L / R )
·Analog input
⇒
Preout output ( Front Wide L / R )
(
b
As the input source, you can switch from CBL/SAT to other ones.)
Pre OUT output
(
b
The Volume -20dB is at the time of Relative setting. Absolute setting is 60dB.)
A19
7.1ch INPUT (signal) Path
A 1 9 7 . 1 I N
* * * . * d B
Input Source : CBL/SAT
Input Mode : 7.1CH IN
Amp Assign : 9.1ch
Speaker Cong : Front, Center, Surround, Surround Back(2ch),
Subwoofer
Vol : 60.0 ( -20dB )
Speaker Cong >> All Speaker = Small / SW = 2ch
·Input : 7.1CH IN
⇒
Output : Speaker output (Front L/R, Center, Surround L/R, S.Back L/R)
·Input : 7.1CH INPUT
⇒
Preout output (Front L/R, Center, Surround L/R, S. Back L/R, Subwooofer)
A20
Front Amp-Height1 (signal) Path
A 2 0 F H 2
* * * . * d B
Input Source : CBL/SAT
Input Mode:Auto
Sound mode: Multi ch Stereo
Vol. : 60.0 ( -20.0dB )
Amp assign:11.1ch
Height Speakers = 4Height Speakers
Height Layout = Top Front & Top Rear
Pre-out Channel = Front & Top Rear
Speaker Conog > >
Surround Back = None
Speaker Select = Floor & Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output (Height1 L / R (Top Front output ))
·Analog input
⇒
Preout output (Height1 L / R (Top Front), Height 2 L / R (Top Rear) )
(
b
As the input source, you can switch from CBL/SAT to other ones.)
PREOUT output
(
b
The Volume -20dB is at the time of Relative setting. Absolute setting is 60dB.)
A21
Front Amp-Front Wide (signal) Path
A 2 1 F W 2
* * * . * d B
Input Source : CBL/SAT
Input Mode:Auto
SURROUND mode: Multi ch STEREO
Vol. : 60.0 ( -20.0dB )
Amp assign:11.1ch
Height Speakers = 2Height Speakers
Height Layout = Front Height
Pre-out Channel = Front & Height2
Speaker Conog >
Speaker Select = Front
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output : Front Wide L/R ( Front Wide signal )
·Analog input
⇒
Preout output (Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
(
b
The Volume -20dB is at the time of Relative setting. Absolute setting is 60dB.)
A23
Wide/Height Amp-Surround Back (signal)
Path
A 2 3 S B
* * * . * d B
Input Mode:Auto
Sound mode: Multi ch Stereo
Vol. : 60.0 ( -20.0dB )
Amp assign:7.1ch + ZONE2
Speakers for ZONE2: Front Wide/Height 2
Height Layout = Front Height
Speaker Select = Floor
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
·Analog
⇒
Speaker output
Surround Back L/R (Surround Back signal)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
(
b
The Volume -20dB is at the time of Relative setting. Absolute setting is 60dB.)
g.12a, g.12b
g.13
g.14a, g.14b
g.15a, g.15b
g.16a, g.16b
30
