Marantz SR7009/U1B - Page 31

3.5.6 Video system conrmation items
g. XX: Refer to the block diagram of the g.XXth.
Conrmation items FL display Settings Contents of conrmation
V01
Analog Video through (signal) Path
V 0 1 V I D E O
* * * . * d B
Input Source : CBL / SAT
Video Convert ( IP Scaler ) : OFF, All sources
MAIN ZONE : ON
ZONE2 : ON
·Component input
⇒
Component output
(
b
As the input source, you can switch from CBL/SAT to other ones.)
V02
video convert
(analog or HDMI
⇒
HDMI)
V 0 2 C O N V .
* * * . * d B
Input Source : CBL/SAT
Video Convert ( IP Scaler ) : ON, All sources
IP Scaler : "Analog&HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
·CVBS input
⇒
IP Scaler Through
⇒
HDMI output
·Component input
⇒
IP Scaler
⇒
HDMI output
·HDMI input
⇒
IP Scaler
⇒
HDMI output
·ETHERNET input
⇒
IP Scaler
⇒
HDMI output
(
b
As the input source, you can switch from CBL/SAT to other ones.)
V03
HDMI through (signal) Path
(Main Zone)
V 0 3 H D M I
* * * . * d B
Input Source : CBL/SAT
Video Convert ( IP Scaler ) : OFF , All Sources
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
·HDMI input ( MAIN Function )
⇒
HDMI output (MAIN)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
V04
CEC
( Control Monitor : HDMI Monitor1 )
V 0 4 C E C
* * * . * d B
Input Source : CBL/SAT
HDMI Control : ON
Control Monitor : Monitor1(HDMI Monitor Out 1)
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
·When the power supply of a TV is put in the standby mode, make sure that the power supply
of this unit is also put in the standby mode.
(
b
As the input source, you can switch from CBL/SAT to other ones.)
·To check ARC path, switch the input source to "TV AUDIO".
V05
HDMI audio
(audio: AVR)
V 0 5 H - A V R
* * * . * d B
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR (audio output from AVR)
·HDMI input(PCM , DolbyDigital , DTS)
⇒
Speaker output
·HDMI input(HD audio)
⇒
Speaker output
(
b
As the input source, you can switch from CBL/SAT to other ones.)
V06
HDMI audio
(audio: TV)
V 0 6 H - T V
* * * . * d B
HDMI Audio : TV (audio output from TV) ·HDMI input(PCM , DolbyDigital , DTS)
⇒
HDMI output (audio output from connected TV)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
V07
OSD
V 0 7 M E N U
* * * . * d B
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog&HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu ON
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
·OSD display
⇒
HDMI output
(
b
As the input source, you can switch from CBL/SAT to other ones.)
V08
HDMI (signal) Path
(ZONE2)
V 0 8 Z 2 H D
* * * . * d B
Input Source : CBL/SAT
ZONE2 Source : Source
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
·HDMI input (ZONE2 Function)
⇒
HDMI output (ZONE2)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.17
g.18a, g.18b
g.19
g.20
g.21a, g.21b, g21c
g.22a, g.22b
g.23
g.24
31
