Menu Key
Figure 11 MENU key.
The MENU key is used to enter the menu where you set the packing weights
(see “Edit Commands – Packing” on page 27) and the grade limits (see “Edit
Commands – Grading” on page 29).
In Setup Mode the MENU key is used to return from submitting commands.
Print Key
Figure 12 PRINT key.
The PRINT key is used for recording and printing weight results. It is also
used for entering commands and for confirming new settings.
Tare Key
Figure 13 TARE key.
The TARE key is used to set the tare. When you press this key with a weight
on the platform, that weight is used as a tare, and the Weight Display will
show a zero. The
NET indicator lights up. The TARE key is also used to
remove tare.
Note: The TARE key cannot be used when Preset Tare is in operation.
Zero Key
Figure 14 ZERO key
The ZERO key is used to take a new operational zero point, provided the
operating zero stays within ±2% of max weight from the initial zero point.
5
The operating zero is the reference point for all weighings, and therefore a
correct operating zero is necessary to ensure accurate weighing results.
5
If automatic zero tracking is set (by activating a software switch, see p. 34), the scale will automatically track small
variations in the zero point. The maximum tracking rate is 0.5 divisions per second.
User’s Guide The M1100 Scale • 13
