Appendix C CAN Connections
The M1100 scale offers the option of CAN connections to other
equipment, hoppers for example. Use of the CAN connections is
described below.
To view CAN network status
1
Press the MENU key and the UP arrow
simultaneously.
2 The current CAN status is displayed on the Weight Display:
•
Preoperational mode. The CAN module has
not been started from the master.
•
Operational mode. The CAN module has
been started from the master.
A steady
to the right in the display indicates
that the CAN bus is active and in order.
A blinking
indicates that
a) the scale’s CAN bus is not connected to the
CAN network or
b) there is no other CAN module on the
network.
3 Press the MENU key to return to Operating Mode.
Note: The CAN network cannot be used on battery operated scales.
