• Response times and transmission rates:
The tables below show the available response times for
M1100 scales.
#A5
17
Response A
#A6
Response B
Response
mode
Response
time
Fixed rate
printout
OFF
OFF
Variable fast
response
~ 0.5 seconds
variable
4.9 Hz
ON OFF Fast response ~ 0.5 seconds 4.9 Hz
OFF ON
Medium response ~ 0.9 seconds 2.4 Hz
ON
ON
Slow response ~ 1.2 seconds 1.2 Hz
#A10 Transmission A #A11 Transmission B Output mode
OFF OFF No continuous printout
ON OFF Event-driven printout
OFF ON Fixed-rate printout
ON ON No continuous printout
• Printout from the
command; example:
M1100: U2-3.10 / CAL=2 / CON=2
App: 1000 0000 0000 0000
Cap: 15.000 kg
Res: Single
CS: 5 kg
C0: 601495
C2: 840888
Gain: 2.088615e-05 kg/cnt
g-adj: 1.00000
Set: 0000 0000 0000 1000
aP: 10.0
aZ: 5.0
aY: 0
aX: 0
bP: 10.0
bZ: 5.0
bY: 0
bX: 0
User’s Guide Appendices • 41
17
In some market areas switches #A5 and A6 may not be available. In such cases their function is selected during
installation.
