The M1100 Scale
About the Scale
The M1100 is an easy to operate, general-purpose packing and grading
scale. The stainless steel enclosure is water-resistant (IP67) and easy to
clean. The scale is available in three basic versions:
• An M1100 indicator mounted on high pillars on a PLx platform
(xxxLx model). This version is also available with a battery option
(xxBLx model).
• An M1100 indicator mounted on short pillars on a PLx platform
(xxxSx model).
• An M1100 indicator with wall or table mountings (xxxNx model)
that can be connected to most weighing platforms with a strain gage
load cell.
Marine and land based
M1100 scales
All three models are available either as motion compensated marine scales
designed specially for use on board fishing vessels or as land based scales.
All models can be used with weighing platforms of various sizes. See
“Appendix D Technical Specifications” on page 43 for more details on
the different models.
Single or multiple range
weighing
The scale is available with a multiple range capability. The availability of
this option, however, depends on the platform type.
This user’s guide applies to the marine scale (M1100-U2) and the land
based scale (M1100-C2). Except for the marine calibration procedure
(see page 16), both types are operated in exactly the same way.
Packing Memories
Up to fifteen packing
memories and four units of
weight
The operator can program the scale with up to fifteen target weights in so-
called packing memories. Each target weight has its own definition of upper
and lower weight limits. Up to four different units of weight (kg, g, lb, or oz)
can be set for each target weight. The Config Display shows which of the
target weight memories, 1 to 15, is in use.
User’s Guide The M1100 Scale • 5
