Turn on the
carrier gas, compressed gas and
instrument power.
Restart the software.
In the leak test dialog box select SV4 and HV
Leak test around the brass connector with a helium
leak detector.
If a leak is detected, g
ently tighten the brass
connector 1/8 tur
n with a 7/16” spanner and check
for leaks again. Repeat until no leak is detected.
DO NOT OVERTIGHTEN OR YOU RISK
BREAKING THE COLD TRAP AGAIN.
