> When the center of work piece and the X,Y and R value of circle doesn`t match each other
A
B
C
D
E
F
A
B
C
D
E
F
A
B
C
D
E
F
A
B
C
D
E
F
A
B
C
D
E
F
P r o b l e m
Normal
The letters
are leaned to the
down
The letters
are leaned to the
one way
The center of
letters and
circle don`t
match
The letters is in
the circle
S o l u t i o n
None
Increase the
value of Y
Increase
the value of X
Adjust the
value of X & Y
Increase the
value of R
% Delicate adjustment of X and Y value on F3 mode %
0152 0152
0151 Press + 0151
Ln X:0150 Y:0150 Ln X : 0150 Y : 0150
(After move the cursor like the above) 0149 Press - 0149
0148 0148
Put the cursor on the coordinates [0000] and press + and – on the keyboard.
Then marking pin move by 0.1mm, can modify marking data.
**Caution – For storing, you have to press “ENTER”key
In case the value of R is bigger than the center of circle X,Y, “Limit Error” on the status window can be
indicated on the screen. In this case, please check the value of R.
