X MOTOR [10000] steps/100mm. : Standard: 10000purse per 100mm
If the value of X MOTOR [10000] STEPS/100MM is changed, Marking machine may work
incorrectly because the figure of marking machine is wrong. Do not modify.
MK-100BS , MK-85BS , SI-120 - > STEP [ 25000 ]
Another all other marking head그 -> STEP [ 10000 ]
Y MOTOR [10000] steps/100mm. : Standard: 10000purse per 100mm
If the value of X MOTOR [10000] STEPS/100MM is changed, Marking machine
may work incorrectly because the figure of marking machine is wrong. Do not modify.
MK-100BS , MK-85BS , SI-120 - > STEP [ 25000 ]
Another all other marking head그 -> STEP [ 10000 ]
SOL. DN DLY : The delay time of sol. Valve when the marking is started. (Default value [0020] )
SOL. UP DLY : The delay time of sol. Valve when the marking is finished. (Default value [0020] )
< In case the value of SOL. DN DLY is small > <In case the value of SOL. UP DLY is small. >
-> Make it the value of SOL.DN DLY and SOL UP DLY higher a little by a little.
END. OUT DLY : Output the “END” signal after marking and keep the output value during 1.5 sec.
Unit of delay [01500] is 0.001sec.
USE PLC SEQUENCE TABLE? : Default value is [Y]. Make it [N] in case you use multi block.
