F7 screen : Marking of the special cha.
and Installation of the file which are created on the AUTO-CAD or Font generator.
In order to use User font, you should carry out this work in advance on the F3 EDIT mode.
F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
LOAD TO [USR1] FONT
STATUS [ ]
[FONT LOAD]
F7 : PLOT LOAD
FILENAME DATA TIME
>< NO FILE >
<Installation of User font>
Can change the menu if press “F7” on the keyboard. Press F7, display is changed to [ FONT LOAD ],
Press F7F7, display is changed to [ PLOT LOAD ].
** How to load User font to the USER1
Press F7 and let the controller displays [FONT LOAD]. Select the no. which is in [ ]
by Enter key on the keyboard. Can select from USER1 to USER 4.
Then put the cursor on ‘<NO FILE>’by PgUP and PgDN key.
In order to see the USER fonts which are saved in the SD card,
press arrow key(↓) if the cursor is on ‘<NO FILE>’
F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
LOAD TO [USR1] FONT
STATUS [ ]
[FONT LOAD]
F7 : PLOT LOAD
FILENAME DATA TIME
< NO FILE >
COLUMBIA.BLK 1998/06/05 12:45
MARKSMAN.BLK 1998/06/05 12:45
JEILMTECH.BLK 1998/06/05 12:45
Selected font will be loaded into the MCU if you press “Enter”key on the keyboard after select the font.
In case Loading is completed, “Reading Data OK” is indicated on the STATUS[ ] window.
Can have new type of font to designated USER 1 ~ 4 on the F3 mode
if the message “Reading data OK”is indicated on the display.
