In order to mark logo file, you should carry out this work in advance on the F3 EDIT mode..
F7 screen : Marking of the special cha.
and Installation of the file which are created on the AUTO-CAD or Font generator.
F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
LOAD TO [PLT1] PLOT
STATUS [ ]
[PLOT LOAD]
F7 : FONT LOAD
FILENAME DATA TIME
>< NO FILE >
** How to load User font to the PLT1
Press F7 and let the controller displays [PLOT LOAD]. Select the no. which is in LOAD TO [PLT1 ]
by Enter key on the keyboard if above screen is displayed. Can select from PLT1 to PLT4.
Then put the cursor on ‘<NO FILE>’by PgUP and PgDN key.
Can see the PLT files which are saved in the SD card If press direction key(↓)
F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
LOAD TO [PLT1] PLOT
STATUS [ ]
[PLOT LOAD]
F7 : FONT LOAD
FILENAME DATA TIME
COLUMBIA.PLT 1998/06/05 12:45
MARKSMAN.PLT 1998/06/05 12:45
JEILMTECH.PLT 1998/06/05 12:45
< NO FILE >
Selected PLT file will be loaded into the MCU if you press “Enter”key on the keyboard
after select the PLT file.
In case Loading is completed, “Reading Data OK” is indicated on the STATUS[ ] window.
Can have new LOGO file to designated PLT 1 on the F3 mode if the message
“Reading data OK”is indicated on the display.
