MARLO MR-210-2 - Page 7

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
4
SPECIFICATION CHART
SYSTEM SIZE
MODEL 150 210 300 450 600 750 900 1050
VALVE SIZE (IN)
1
14 12
2
14 12
2
22 12
2
22
3
12
2
22
3
12
2
22
3 2
22
3 2
22
3 2
22
3
MAX CAPACITY (KILOGRAINS)
150 210 300 450 600 750 900 1050
MIN CAPACITY (KILOGRAINS)
100 140 200 300 400 500 600 700
FLOWRATE (GPM)
SERVICE - CONTINUOUS (GPM)
32 42 45 57 41 64 80 115 68 92 140 165 63 82 120 140 72 110 140 175 90 140 160 105 150 188 95 135 173
SERVICE - PEAK (GPM)
55 78 69 97 57 86 110 160 92 125 190 230 90 115 170 190 94 125 190 250 116 190 230 133 218 279 124 210 259
BACKWASH & FAST FLUSH
(GPM)
10 15 20 20 30 30 45 45
BRINE DRAW & RINSE (GPM)
2.5 3.5 5 5 7 7 10 10
TIMER
SETTINGS
BACKWASH & FAST FLUSH (MIN)
10 10 10 10 10 10 10 10
BRINE DRAW & RINSE (MIN)
60 60 60 60 60 60 60 60
FAST FLUSH (MIN)
6 6 6 6 6 6 6 6
SOFTENER TANK
SIZE (IN)
20x54 24x54 30x54 30x60 36x60 36x72 42x60 42x72
GRAVEL (LBS)
100 200 300 300 400 400 600 600
RESIN (FT
3
)
5 7 10 15 20 25 30 40
FREEBOARD (IN)
24 24 27 20 23 27 20 25
BRINE SYSTEMS
EQUIPMENT
TANK SIZE
24x50 24x50 24x60 30x60 39x60 39x60 42x60 50x60
MAX SALT STORAGE (LBS)
700 600 600 1000 1900 1700 1900 2300
INJECTOR CODE
2.0-050 3.5-075 5.0-075 5.0-075 7.0-100 7.0-100 10.0-100 10.0-100
INJECTOR COLOR
RED WHT BLUE BLUE RED RED WHT WHT
SALT
SALT DOSAGE- MAX (LBS)
75 105 150 225 300 375 450 525
SALT DOSAGE- MIN (LBS)
30 42 60 90 120 150 180 210
BRINE VALVE FLOAT HEIGHT - MAX 12 19 26 26 19 26 26 19
BRINE VALVE FLOAT HEIGHT - MIN 3 8 9 9 8 9 9 8
