MARLO MR-210-2 - Specification Table

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
3
DIMENSION CHART
MODEL
PIPE SIZE DIMENSION TABLE
INLET/OUTLET DRAIN INJECTOR HEIGHT WIDTH LENGTH
MR-150-1 1 1
2.0-050 6’-0”
2’-5”
7’-4”
MR-150-1-1/4 1-1/4 1 2’-6”
MR-150-1-1/2 1-1/2 1 2’-6”
MR-150-2 2 1 2’-10”
MR-210-1-1/4 1-1/4 1
3.5-075 6’-1”
2’-8”
8’-0”
MR-210-1-1/2 1-1/2 1 2’-8”
MR-210-2 2 1 3’-0”
MR-210-2-1/2 2-1/2 1 3’-1”
MR-300-1-1/2 1-1/2 1
5.0-075 6’-4”
3’-2”
9’-0”
MR-300-2 2 1 3’-6”
MR-300-2-1/2 2-1/2 1 3’-7”
MR-300-3 3 1 3’-8”
MR-450-1-1/2 1-1/2 1
5.0-075 6’-10”
3’-2”
9’-6”
MR-450-2 2 1 3’-6”
MR-450-2-1/2 2-1/2 1 3’-7”
MR-450-3 3 1 3’-8”
MR-600-1-1/2 1-1/2 1-1/2
7.0-100 7’-5”
3’-8”
11’-3”
MR-600-2 2 1-1/2 4’-0”
MR-600-2-1/2 2-1/2 1-1/2 4’-1”
MR-600-3 3 1-1/2 4’-2”
MR-750-2 2 1-1/2
7.0-100 8’-5”
4’-0”
11’-3”MR-750-2-1/2 2-1/2 1-1/2 4’-1”
MR-750-3 3 1-1/2 4’-2”
MR-900-2 2 2
10.0-100 7’-10”
4’-6”
12’-6”MR-900-2-1/2 2-1/2 2 4’-7”
MR-900-3 3 2 4’-8”
MR-1050-2 2 2
10.0-100 8’-10”
4’-6”
13’-2”MR-1050-2-1/2 2-1/2 2 4’-7”
MR-1050-3 3 2 4’-8”
