Marport CATCH - Technical Specifications

Measures • Battery (always activated)
• Catch (always activated)
• Pressure (depth)
• Temperature
• Pitch
• Roll
• Height
Technical Specifications
Uplink frequency 30 to 60 kHz
Range to vessel up to 2500 m*
Data update rate • 5-meter range: Echogram @0.75 s - temperature, depth, pitch, roll,
battery level, catch @5.24 s
• 10-meter range: Echogram @0.91 s - temperature, depth, pitch,
roll, battery level, catch @6.39 s
• 20-meter range: Echogram @1.24 s - temperature, depth, pitch,
roll, battery level, catch @8.69 s
• 40-meter range: Echogram @1.00 s - temperature, depth, pitch,
roll, battery level, catch @7.00 s
• 80-meter range: Echogram @1.26 s - temperature, depth, pitch,
roll, battery level, catch @8.85 s
• 160-meter range: Echogram @1.79 s - temperature, depth, pitch,
roll, battery level, catch @12.53 s
Depth range up to 1800 m
Depth resolution 0.1 m with 0.1% full scale accuracy
Echogram range 20 (auto) / 40 / 80 / 160 meters
Pitch and roll range -180° to +180°
Pitch & roll accuracy +/- 1°
Temp measurement range -5° C to +25° C
Temp accuracy ±0.1° C
