Trawl Explorer | V2 | Sensor Configuration
Configuring the Uplink, Up and Down Settings
You can configure different settings for uplink, down and up soundings.
Before you begin
The sensor is connected to Mosa.
About this task
Remember: Always click Apply after you change a setting and make sure there is a green
check mark .
Procedure
Click the tab Trawl Explorer.
Uplink
Procedure
From TE Uplink Frequency, enter a frequency for the signal toward the vessel.
Important: This parameter must be the same in the sensor settings in Scala.
Up/Down Soundings
Procedure
1.
From NBTE Setup Options, select the sounding mode (see Sounding Modes on page 15 for more
information).
| 16
