Trawl Explorer | V2 | System Configuration and Display
System Configuration and Display
Learn how to configure the receiver to be able to receive and display Trawl Explorer sensor data.
Note: This guide refers to the following versions of Scala: 01.06.06-01.06.14 . If you use
another version, the visual interface and options may vary.
Adding the Sensor to the Receiver
You need to add the Trawl Explorer to the receiver in order to display sensor data on Scala.
About this task
The Trawl Explorer is compatible with the following M3/M4/M5/M6 receiver and Scala versions:
Mx version Scala version
NBTE V1 (FIRM121) all all
NBTE V2 (FIRM126) 03.01.23 or later all
NBTE V3 (FIRM128) 04.02.28 or later 01.02.05 or later
Adding the Sensor with a Configuration File
You can add the sensor to the receiver with a configuration file that contains the sensor settings
you configured on Mosa.
Before you begin
• You have exported an XML file containing the sensor settings (See Exporting Sensor
Configuration for Receiver on page 26).
Important: You need to have Firefox version 22 to 51.
Procedure
1.
Enter your receiver IP address in Firefox web browser to access the system control panel web
page.
Note: Default IP addresses are: 192.168.10.177 for M3 and M6 receivers, 192.168.1.170 for
M4 receiver. Add the address as a bookmark in Firefox to easily connect to it.
| 28
