Frequencies and intervals
The diagrams below show the bandwidth of the different types of Marport sensors and intervals
you must respect when adding other sensors.
Note: The bandwidth of wide band HDTE is 1200 kHz. Intervals are the same.
Figure 2: PRP sensors (e.g. Catch sensor, Trawl Speed, Spread sensor...)
Figure 3: NBTE sensors (e.g. Speed Explorer, Trawl Explorer, Catch Explorer, Door Sounder)
Figure 4: HDTE
Bandwidth
Mandatory distance with other
sensors
Recommended distance with other
sensors
