marposs IWAVE2 - Technical Specifications

24 / - Instruction Manual
Technical specifications
Degree of sealing
 I-Wave 2
IP67 (IEC-60529 e EN-60529)
 Wave 2 (with assembled connector)
IP67 (IEC-60529 e EN-60529)
Weight (without plug head)
540 gr (I-Wave2)
505 gr
(Wave2)
Resolution
0,1 µm (*)
Linearity error
0,3 µm on a travel of 5 mm (I-Wave2)
Maximum accuracy error
+/-0,5% reading +/- resolution (**)
Battery (***)
type
Integrated Li-Ion rechargeable
3,6V - 2600 mA/h
Duration in continuous use 40 h (****)
Duration in standby mode
50 days
Duration in Sleep mode
5 years
100% charging time to 20°
10h (typical)
100% charging time to 40°
20h (typical)
(*) Note: Function settable only from FW 2.0.2/1.3.0.
(**) Note: the accuracy error refers to the Wave2 handle only. The accuracy error of
the complete measuring instrument must be calculated taking into account the type
of capsule used.
(***) Note: typical values for a new battery under ideal conditions
(fully-charged; @ 20 °C).
(****) Note: The duration of the batteries can be further increased setting
programmable auto-shutdown option (standby).
Technical specifications
Environment
al conditions
of utilisation
During operation
5°C - 45°C
During recharge
5°C - 35°C
5°C - 40°C
with Stand charger in high temperature
Operating Mode
Maximum relative humidity
90%
Maximum temperature
change
2°C/h
Degree of pollution 2 (EN 61010-1)
Position Wet (EN 61010-1)
Type of installation / use indoor
