marposs IWAVE2 - Replacing the Rear Cover; Removing the Rear Cover

86 / - Instruction Manual
9.2 Replacing the rear cover
Below are listed the operations necessary for the replacement of the rear cover
9.2.1 Removing the rear cover
1. Using an Allen Key (D=1,27mm), remove the screws (1), (2), (3) and (4).
2. Remove the rear cover (5).
2
1
4
3
5
