34 / - Instruction Manual
4.3 Stand charger
Stand charger is available in two versions:
Nose-up
Nose-down
Nose-up Nose-down
Figure 4-9. Stand charger.
WARNING
Do not obstruct the heat sink of the stand charger with objects.
4.3.1 Meaning of multicolor LED
LED Colour Meaning
Green
Power supply present, no handle detected.
Blue
Power supply present, handle detected and under charge.
Red
Power supply present, foreign object detected, wireless
power is suspended.
Blinking for 3 sec., only when connecting the power
supply, indicates the operating mode for high
temperatures (available only for codes 2T0IRBS030/31.
i
INFORMATION
To set the operating mode for high temperatures, contact Marposs.
Green
Blue
Red
Green
Blue
Red
Multicolor led
Multicolor led
