Chapter 5 INSTRUCTIONS FOR USE 45
Symbol Description
Measure on hold (Stand Alone mode)
Measure zeroing
Transducer zeroing
Settings menu
5.2.2 Setting the measurement resolution and unit of
measurement
The following table displays the available combinations of resolution and units of
measure:
Measurement
Resolution
Micron (um) Millimeter (mm) Inches (inch)
Resolution 1 0,1 0,0001 0,00001“
Resolution 2 0,2 0,0002 0,00002“
Resolution 5 0,5 0,0005 0,00005“
Resolution 10 1 0,001 0,0001“
Refer to the “Wave2 Driver” User Manual for instructions and settings.
