Chapter 6 INSTALLATION OF PLUG HEAD 65
6.2.3 Plug head replacement procedure
1) Make sure to use the correct adapter
(see 6.2.1 and 0 paragraphs).
2)
Screw the adapter (1) to the plug head (2).
3) The mechanical interface is a steel adapter screwed on to the thread of
the plug head and forms a small sub assembly. Insert the sub-assembly
formed by the plug head and the adapter into the corresponding housing,
making sure that the adapter is flush.
2
1
16/AF
