88 / - Instruction Manual
2. Insert the resulting sub-assembly (rear cover and seal) on the handle, so
that
the antenna (A) rests inside the housing (B) on the rear cover, as
shown in the figure.
3. Using the Allen Key, tighten the screws (1), (2), (3) and (4).
