Martin DESIGNER User Manual

10 53D0419
53D0419 11










Figure 6 - Top View of Framing
Inside Corner (Right-Hand Configuration)
Figure 7 - Framing for Corner Units
Gas
Connection
FRAMING CORNER FIREPLACE
1/2" DRYWALL 5/8" DRYWALL
A1 43
1
/2" 43
3
/8"
A2 39
7
/8" 39
3
/4"
B 41
1
/8" 41
1
/8"
C 24" 23
7
/8"
INSIDE CORNER FRAMING
SPECIFICATIONS
2"x4"
2"x2"
(Minimum)
2"x4"
(Minimum)
2"x2"
(Minimum)
FRAMING FIREPLACE

Martin DESIGNER Specifications
