Martin DESIGNER User Manual

12 53D0419
53D0419 13









FRAMING FIREPLACE
Figure 8 - Top View of Framing for
See-Through Unit
Figure 9 - Framing
Installing for See-Through Unit
Gas
Connection
2"x4"
(Minimum)
Install 2"x4" (Minimum)
after fireplace is set
into framed A1 Opening
1/2" DRYWALL 5/8" DRYWALL
A1 44
1
/4" 44
1
/4"
A2 40
5
/8" 40
5
/8"
B 41
1
/8" 41
1
/8"
C 22
3
/4" 22
1
/2"
*SEE THROUGH FRAMING
SPECIFICATIONS
FRAMING SEE THROUGH FIREPLACE
* Note: For ease of installation, frame around the firebox after it has been set. See chart below for
specifications.
When installing into existing framed (A1) openings, loosen the junction box. Remove the rear-mounted ue pipe adaptor.
See page 17, gures 13 and 14. Reattach both assemblies.
