53D0419 43
120 VAC
Blower
120 VAC
Speed Control
Green Green
Attach Blower to T-Stat
Black
Black
Black
White
Blower Plug
Junction Box
ON/OFF Wall Switch or
Optional Variable Speed Switch
120 VAC
60Hz
Factory Supplied
Not Supplied
GLASS REPLACEMENT AND BLOWER
• Never operate replace if glass is broken.
• Replace any glass that is chipped, cracked, or broken. Replacement glass assemblies MUST be supplied by replace
manufacturer — No substitute materials may be use.
Always use gloves when handling
broken glass.
CAUTION
Make sure the glass panel edges
do not touch any metal parts during
thermal expansion.
WARNING
OPTIONAL BLOWER ACCESSORY - BLOT
WIRING DIAGRAM FOR BLOWER
