Masimo NomoLine ISA AX+ User Manual

NomoLine ISA Service Manual Chapter 2: Maintenance Procedures
www.masimo.com 21 Masimo
• Tubing with ID 5.5 mm (7/32”) (connects to manual pressure gauge meter)
• 4-way stopcock lever set in the position shown
• 3-way connector
• Manual pressure gauge meter. See Additional Equipment Required on page 15.
Figure 1-8
Item Description Item Description
1 Syringe 3 Connect to the Manual Pressure gauge with
appropriate tubing.
2 Connect to the ISA Exhaust
Port*
4 Connect to the ISA Input Connector*
* See NomoLine ISA CO2/AX+ Interface on page 11 or ISA OR+ Interface on page 12.
