Masimo O3 User Manual

O3 Regional Oximeter Chapter 3: Setting Up the O3 System
www.masimo.com 20 Masimo
2. Insert the MOC-9 connector securely into a MOC-9 Port on Root, as illustrated in
the image below.
3. The module is now activated. This is verified when the O3 Module window displays
on Root with all parameters and measurements dashed out because no O3 Sensor
has been connected to the module.
For more information on the O3 Module window, see The O3 Module Window on page 25.
Repeat the steps above for the second module if more than two sensors are intended to be
used.
