www.masimo.com 19 Masimo
Chapter 3: Setting Up the O3 System
For initial use of O3 System, the following setup instructions must be followed.
Unpacking and Inspecting the System
1. Remove the components from the shipping carton and examine them for signs of
shipping damage.
2. Check all materials against the packing list. Save all packing materials, invoice
and bill of lading. These may be required to process a claim with the carrier.
3. If anything is missing or damaged, contact the Masimo Technical Service
Department.
Preparation for Use
Prior to using the O3 System for monitoring
1. Confirm that you have all system components:
• Root
• O3 Module
• O3 Sensor(s)
2. Confirm that Root holds adequate battery power.
Connecting the O3 Module to Root
Up to two O3 Modules can be connected to Root.
To connect a Module to Root:
1. Identify the Masimo Open Connect (MOC-9
TM
) connector on the O3 module, as
illustrated in the image below.
