Radical-7 Chapter 4: Operation
www.masimo.com 105 Masimo
Options Description Factory
Default
Settings
Configurable Options
High Limit The High Limit is upper
threshold that triggers
an alarm.
30
breaths
per
minute
6 to 69 breaths per
minute in steps of 1
breaths per minute,
or Off
Low Limit
The Low Limit is lower
threshold that triggers
an alarm.
6 breaths
per
minute
5 to 68 breaths per
minute in steps of 1
breaths per minute
Respiratory
Pause
The duration of time
that triggers an alarm if
no breaths are
detected.
30
seconds
20, 25, 30, 35, 40, or
15 seconds
Alarm Delay When a High or Low
alarm condition occurs,
this feature delays the
audible part of an
alarm.
30
seconds
60, 0, 10, 15, or 30
seconds
Additional Settings for RRa
From the Additional Settings screen, change any of the following options:
